Vishay 800 V 180 A Through Hole Bridge Rectifier GSIB680-E3/45

Free Delivery in India | Lowest Global Shipping Charges

Vishay 800 V 180 A Through Hole Bridge Rectifier GSIB680-E3/45

Name: Vishay 800 V 180 A Through Hole Bridge Rectifier GSIB680-E3/45
Brand: Vishay
SKU: 136046
Price: 2.89 USD
Availability: InStock



Category Bridge Rectifier Brand Vishay Condition New

Specifications

Country of Origin	China
Brand	Vishay
Height	20mm
Length	30mm
Model	GSIB680-E3/45
Width	4.6mm
Mount Type	Through Hole
Series	GSIB6
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	GSIB-5S
Minimum Operating Temperature	-55°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	800V
Peak Reverse Current Ir	10μA
Peak Non-Repetitive Forward Surge Current Ifsm	180A
Forward Current If	6A
Peak Forward Voltage Vf	950mV
HY Electronic Corp Bridge Rectifier, 6A, 600V, 4-PinBrand	HY Electronic Corp

Key Features

Designed for single-phase full-wave rectification applications.
Features high surge current capability and high dielectric strength case of 2500 Vrms.
Operates reliably from -55°C to 150°C maximum temperature.
Glass passivated chip junction ensures durability and longevity.
Soldering pins provide secure PCB through-hole mounting.
Peak forward voltage is 950 mV, ensuring efficient conduction.
Low peak reverse current of 10 μA for minimal leakage.
Ideal for industrial, electronic, and power rectification applications.

Product Description

Vishay GSIB680-E3/45 bridge rectifier is a high-performance electronic component specifically designed to convert AC input into DC output, enabling full-wave rectification for single-phase systems. The device features 800 V peak reverse repetitive voltage and a substantial 180 A peak non-repetitive forward surge current capacity, making it suitable for demanding power conversion needs.

Encapsulated in a rugged GSIB-5S package with 4 soldering pins, the rectifier allows through-hole PCB mounting for reliable mechanical and electrical connections. Its compact dimensions (30 mm length, 20 mm height, 4.6 mm width) and glass passivated chip junction contribute to its durability and thermal stability.

This bridge rectifier supports operation within -55°C to 150°C temperature range, ensuring consistent performance even in harsh industrial environments. The device's high dielectric strength case withstands voltages up to 2500 Vrms, providing enhanced safety margins for power circuitry.

Single-phase Bridge Rectifier for full-wave AC to DC conversion. High surge current tolerance ensures robustness under transient conditions. Low forward voltage drop of 950 mV minimizes power losses. High insulation voltage case enhances device reliability.

Compact SIL PCB mount package for easy integration. Temperature range from -55°C to 150°C supports versatile applications. Perfect for power supplies, industrial controls, and electronic instrumentation.

This product is essential for electronic, industrial, and power supply applications requiring efficient bridge rectification with reliable thermal and electrical specifications. The GSIB680-E3/45 series delivers proven performance and durability to optimize system efficiency.

Explore more Vishay semiconductor components and related industrial electronic products at EnvMart.
