TDK Film Capacitor 470 nF 160V AC 450 V DC Through Hole Mount B32671P4474K000

TDK B32671P4474K000 is a high-quality film capacitor designed for electronic components requiring stable capacitance and high voltage tolerance. This capacitor features a 470 nF capacitance with a rated AC voltage of 160V and a DC voltage rating of 450V. Mounted using the through hole technique, it has a standard lead pitch of 10 mm and a lead diameter of 0.6 mm, making it suitable for robust and reliable circuit assemblies.

The metallised polypropylene film technology ensures excellent self-healing properties, high-frequency AC operation, and high ripple and peak current capability. The compact design with dimensions of length 13 mm, width 6 mm, and height 14 mm allows for efficient PCB space utilization even in dense component layouts.

Operating at maximum temperatures up to 125°C, this capacitor complies with automotive standard AEC-Q200 Rev D, making it appropriate for automotive and industrial-grade applications. It features a plastic case with UL 94 V-0 rating and epoxy resin sealing that provide durability and insulation.

Applications include power factor correction circuits, high-frequency switching circuits, and general electronic and industrial use where reliable film capacitors are required. The product meets UL and RoHS approvals, ensuring both safety and environmental friendliness. This capacitor is halogen-free and RoHS compatible, making it an environmentally preferable choice.

Compact metallised polypropylene film capacitor design for high performance. Rated voltage of 160V AC and 450V DC suitable for demanding applications. Through hole mounting with 10 mm lead pitch and 0.6 mm lead diameter.

Maximum operating temperature of 125°C for reliable operation. Compliant with automotive standard AEC-Q200 Rev D for automotive use. Plastic case with epoxy sealing provides excellent insulation and protection. Capacitor dimensions: length 13 mm, width 6 mm, height 14 mm for compact PCB layouts.

Features UL and RoHS approvals ensuring safety and environmental compliance. Ideal for power factor correction circuits and high-frequency AC operation. Explore the extensive range of Film Capacitors and electronic components from TDK at EnvMart for reliable industrial and automotive solutions.
