DiodesZetex Barrier Rectifier Diode 20 A 200 V 3-Pin TO-220F SBR20A200CTFP
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 16.07mm |
| Length | 16.07mm |
| Model | SBR20A200CTFP |
| Width | 10.31mm |
| Mount Type | Through Hole |
| Series | 20A SBR |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-220F |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Barrier |
| Peak Reverse Current Ir | 1mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 180A |
| Maximum Forward Voltage Vf | 960mV |
| Peak Reverse Recovery Time trr | 25ns |
Key Features
- Maximum continuous forward current rating of 20 amperes provides robust performance.
- Peak reverse repetitive voltage of 200 volts supports high voltage applications.
- 3-pin TO-220F package enables easy through-hole mounting.
- Peak non-repetitive forward surge current up to 180 amperes enhances transient handling capability.
- Wide operating temperature range from -65°C to 175°C ensures adaptability in varied environments.
- Peak reverse current of only 1 milliampere minimizes leakage losses.
- Low maximum forward voltage of 960 millivolts reduces conduction losses.
- Fast peak reverse recovery time of 25 nanoseconds improves switching efficiency.
Product Description
DiodesZetex SBR20A200CTFP Barrier Rectifier Diode is engineered as a Schottky barrier diode with a 3-pin TO-220F package, supporting a maximum continuous forward current of 20 A and a peak reverse repetitive voltage of 200 V. This diode is suitable for applications requiring high reliability and thermal stability.
The device features a common cathode diode configuration and is manufactured for through-hole mounting, facilitating integration into various power electronics assemblies. With a maximum forward voltage drop of 960 mV, the diode ensures efficient power handling with minimal losses.
Its peak non-repetitive forward surge current of 180 A allows it to withstand transient surge events, while the peak reverse current is limited to 1 mA for low leakage. The fast peak reverse recovery time of 25 ns enhances switching speeds, making it suitable for high-frequency applications.
The diode operates reliably over a broad temperature range from -65°C to 175°C and complies with automotive standard AEC-Q101, ensuring durability under demanding operating conditions.
This product finds applications in industrial electronic equipment, power rectification, automotive electronics, and general-purpose power supplies requiring efficient rectification and barrier diode characteristics.
Maximum continuous forward current rating of 20 amperes provides robust performance. Peak reverse repetitive voltage of 200 volts supports high voltage applications. Peak non-repetitive forward surge current up to 180 amperes enhances transient handling capability.
Wide operating temperature range from -65°C to 175°C ensures adaptability in varied environments. Fast peak reverse recovery time of 25 nanoseconds improves switching efficiency. Low peak reverse current of 1 milliampere minimizes leakage losses.
Common cathode diode configuration for standard circuit use. TO-220F 3-pin through-hole package for secure mounting. Compliance with automotive standard AEC-Q101 guarantees reliability. Explore the Electronics & Electricals section at EnvMart for more Schottky Diodes & Rectifiers options and trusted DiodesZetex products.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of this diode is 20 amperes.
The peak reverse repetitive voltage for this model is 200 volts.
This diode comes in a TO-220F package type, which is designed for through-hole mounting.
The peak non-repetitive forward surge current is up to 180 amperes.
The diode operates over a wide temperature range from -65°C to 175°C.
The peak reverse current is limited to 1 milliampere, which minimizes leakage losses.
The maximum forward voltage drop is 960 millivolts, which helps reduce conduction losses.
The peak reverse recovery time is 25 nanoseconds, enhancing switching efficiency.
This model features a common cathode diode configuration suitable for standard circuit use.
The diode complies with the automotive standard AEC-Q101, ensuring reliability under demanding conditions.
The dimensions of this diode are 16.07 mm in height and length, and 10.31 mm in width.
This diode is suitable for applications in industrial electronic equipment, power rectification, automotive electronics, and general-purpose power supplies.
