TDK 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 1 μH ±10% 400 mA Idc Q:30 B82422T1102K000
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 2mm |
| Length | 3.2mm |
| Model | B82422T1102K000 |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | B82422T |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 1μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 400mA |
| Pin Count | 2 |
| Maximum DC Resistance | 600mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 300MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 1210 package case suitable for surface mounting.
- Ferrite core material with shielded construction reduces electromagnetic interference.
- Maximum DC resistance of 600 mΩ ensures low power loss.
- Operating temperature range from -55°C to 125°C for diverse environments.
- Complies with RoHS standard and meets AEC-Q200 automotive standard.
- High self-resonant frequency of 300 MHz for effective filtering applications.
- Packaged in Tape & Reel format for efficient automated PCB mounting.
- Minimum quality factor of 30 guarantees signal integrity in high-frequency circuits.
Product Description
TDK B82422T1102K000 1210 Shielded Wirewound Surface Mount Inductor with a Ferrite Core offers an inductance of 1 μH with ±10% tolerance, capable of carrying a maximum DC current of 400 mA and a quality factor of 30. It is constructed with a shielded ferrite core designed to reduce electromagnetic interference and support high-frequency applications up to 300 MHz.
This inductor features a compact 1210 package with dimensions approximately 3.2mm length, 2mm height, and 2.5mm depth, suitable for surface mount installation. It is RoHS-compliant and meets the automotive AEC-Q200 standard, making it ideal for automotive, telecommunications, consumer electronics, industrial electronics, and data processing equipment applications.
The operating temperature ranges from -55°C to 125°C allowing reliable use in harsh environments. The construction includes a wirewound coil with moulded assembly to ensure mechanical durability. The inductor has a maximum DC resistance of 600 mΩ, ensuring efficient power handling and low heat generation.
Compact 1210 surface mount package ideal for automated PCB assembly. Shielded ferrite core minimizes electromagnetic interference. 1 µH inductance with ±10% tolerance supports precision filtering. Maximum DC current rating of 400 mA suitable for low-power circuits.
High quality factor of 30 ensures excellent signal quality. Maximum self-resonant frequency of 300 MHz enables high-frequency applications. Wide temperature tolerance from -55°C to 125°C. Compliant with RoHS and automotive AEC-Q200 standards for safety and reliability.
Tape & Reel packaging for efficient production processes. Reliable solder termination with 2 pin count enhances connection stability.
This surface mount inductor from TDK is well suited for power supply filtering, coupling and decoupling circuits, antenna systems, and automotive electronic applications. Its shielded core and stable performance at high frequencies make it effective for telecommunications and consumer electronics devices. This product benefits manufacturing and engineering professionals looking for dependable, high-quality Surface Mount Inductors for demanding industrial and commercial uses.
Explore the range of inductors and electrical components in the Electronics & Electricals category at EnvMart for innovative circuit design and industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 1 μH with a tolerance of ±10%.
This inductor has a maximum DC current rating of 400 mA.
The dimensions of this unit are approximately 3.2 mm in length, 2 mm in height, and 2.5 mm in depth.
It operates within a temperature range of -55°C to 125°C.
The maximum self-resonant frequency is 300 MHz, making it suitable for high-frequency applications.
It features a ferrite core, which helps reduce electromagnetic interference.
This model is packaged in Tape & Reel format, which is efficient for automated PCB mounting.
It complies with RoHS standards and meets the AEC-Q200 automotive standard.
The minimum quality factor is 30, ensuring good signal integrity in high-frequency circuits.
The termination style is solder, with a pin count of 2 for stable connections.
This inductor is suitable for applications in automotive electronics, telecommunications, consumer electronics, and industrial electronics.
The maximum DC resistance is 600 mΩ, which helps ensure low power loss.
