| Country of Origin | China |
|---|---|
| Brand | onsemi |
| Height | 1.01mm |
| Length | 3.04mm |
| Model | BAS70-04LT1G |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | BAS70-04L |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 15mA |
| Peak Reverse Repetitive Voltage Vrrm | 70V |
| Diode Configuration | Series |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100mA |
| Maximum Forward Voltage Vf | 1V |
| Nexperia 70 V 70 mA Diode Schottky 3-Pin SC-70Brand | Nexperia |
onsemi BAS70-04LT1G Schottky Diode is a 3-pin SOT-23 surface mount device designed for efficient low voltage, high-frequency rectification. It features a Schottky barrier construction providing a low forward voltage drop with minimal reverse leakage, making it ideal for applications requiring compact size and weight.
This diode supports a maximum continuous forward current of 15 mA and can withstand peak reverse repetitive voltages up to 70 V. The maximum forward voltage is 1 V, which aids in reducing power loss and heat dissipation in power conversion and switching circuits.
The device operates reliably across a temperature range from -55°C to 150°C and is encapsulated in an epoxy moulded case that offers stress protection and robustness. Weighing only 11.7 mg, it suits miniature electronic designs where board space and weight are critical.
Compliant with the AEC-Q101 automotive qualification standard, the BAS70-04LT1G diode is suitable for automotive, industrial, and consumer electronics requiring high reliability and performance in challenging environments.
Typical use cases include polarity protection, freewheeling diodes in power supplies, and fast switching applications in circuits demanding a low forward voltage drop and minimal reverse current.
Maximum continuous forward current: 15 mA. Peak reverse voltage: 70 V. Operating temperature range: -55°C to 150°C. Package type: 3-Pin SOT-23 surface mount. Automotive qualification: AEC-Q101 compliant. Epoxy moulded lightweight case of 11.7 mg.
Low forward voltage drop of 1 V. Pb-Free and RoHS compliant manufacturing.
Ensure efficient and reliable circuit design with the onsemi BAS70-04LT1G diode. Suitable for a broad range of industrial, automotive, consumer electronics, and laboratory applications requiring precise and durable semiconductor components.
Explore more Schottky Diode options and related semiconductor products with EnvMart's comprehensive portfolio.
