onsemi Transistor 2 A NPN 40 V DC 3-Pin SOT-23 NSS40201LT1G

onsemi NSS40201LT1G is a general-purpose NPN bipolar transistor designed for switching and amplification applications in electronic circuits.

The device features a maximum collector current of 2 amps and can withstand a collector emitter voltage of up to 40 volts DC, making it suitable for moderate power electronic devices.

Packaged in a compact SOT-23 surface mount package with 3 pins, it offers optimized footprint in circuit board designs. The transistor provides a minimum current gain (hFE) of 180, ensuring effective amplification in low to medium frequency circuits up to 100 MHz transition frequency.

Its power dissipation rating is 460 mW, balanced for typical general-purpose semiconductor requirements. The operating temperature range from -55°C to 150°C allows reliable performance even in industrial and harsh environments.

This transistor is ideal for use in industrial electronic equipment, power management modules, control systems, and other semiconductor applications requiring compact and reliable switching elements.

This transistor supports a maximum DC collector current of 2 amperes. It has a maximum collector emitter voltage rating of 40 volts DC. The transistor package type is compact SOT-23 with 3 pins. Designed for single transistor configuration and surface mount technology mounting type.

Offers a minimum DC current gain (hFE) of 180 for efficient current amplification. The maximum power dissipation is rated at 460 milliwatts, suitable for general purpose use. Supports a maximum transition frequency of 100 MHz for high-speed switching.

Operating temperature range is broad from -55°C up to 150°C, accommodating harsh environments. Dimensions are approximately 3.04 mm length, 2.64 mm width, and 1.11 mm height. These transistors are not automotive standard certified but comply with general industrial requirements.
