Vishay MKP386M Film Capacitor 220 nF ±5% 2 kV DC Screw Mount MKP386M
Specifications
| Country of Origin | Portugal |
|---|---|
| Brand | Vishay |
| Height | 38mm |
| Length | 44mm |
| Model | MKP386M |
| Width | 22mm |
| Mount Type | Screw |
| Series | MKP386M |
| Maximum Operating Temperature | 85°C |
| Tolerance | ±5 % |
| Capacitance | 220nF |
| Minimum Operating Temperature | -50°C |
| Terminal type | Screw Mount |
| Lead Length | 6mm |
| Standards/Approvals | IEC 60384-17 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated DC Voltage | 2kV dc |
| Lead Pitch | 28mm |
| Lead Diameter | 0.8mm |
| Equivalent Series Resistance ESR | 10mΩ |
Key Features
- Constructed with a plastic case for durability and insulation.
- Designed for direct mount applications with screw terminals and 28 mm lead pitch.
- Operates reliably in temperatures from -50°C to 85°C.
- Features low equivalent series resistance (ESR) of 10 mΩ for efficient performance.
- Complies with IEC 60384-17 standards ensuring quality and safety.
- Ideal for applications including photovoltaic systems, wind inverters, motor drives, and frequency converters.
- Compact dimensions measuring 44 mm length, 22 mm width, and 38 mm height.
- Lead diameter is 0.8 mm with a 6 mm lead length, supporting robust electrical connections.
Product Description
Vishay MKP386M Film Capacitor MKP386M is a high-quality film capacitor with a capacitance of 220 nF and a tolerance of ±5%. It is rated for 2 kV DC voltage and features a screw mount terminal type, designed for direct mounting on IGBT modules and similar power electronic components.
Constructed with a durable plastic case, this capacitor has a lead pitch of 28 mm, lead length of 6 mm, and lead diameter of 0.8 mm. It offers a low equivalent series resistance (ESR) of 10 mΩ, ensuring efficient electrical performance and reduced energy losses.
Operating effectively within a temperature range of -50°C to 85°C, the MKP386M capacitor complies with IEC 60384-17 standards, providing reliability and safety for industrial and commercial electronic applications.
This capacitor is especially suited for use in photovoltaic systems, wind inverters, motor drives, and frequency converters where EMI reduction and high pulse strength are critical. It features low inductance construction and supports high dV/dt up to 2500 V/μs for reliable transient response.
Compact dimensions of 44 mm length, 22 mm width, and 38 mm height make it suitable for space-constrained assemblies. The product is manufactured in Portugal and delivered in new condition.
Constructed with a plastic case for durability and insulation. Designed for direct mount applications with screw terminals and 28 mm lead pitch. Operates reliably in temperatures from -50°C to 85°C. Features low equivalent series resistance (ESR) of 10 mΩ for efficient performance.
Complies with IEC 60384-17 standards ensuring quality and safety. Ideal for photovoltaic, wind inverter, motor drive, and frequency converter applications. Compact dimensions of 44 mm length, 22 mm width, and 38 mm height.
Lead diameter of 0.8 mm and lead length of 6 mm ensure solid electrical connections. Manufactured in Portugal with new condition assurance. Explore more Vishay Film Capacitors and related electronic components on EnvMart for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MKP386M film capacitor has a capacitance value of 220 nF.
This model is rated for a DC voltage of 2 kV.
It operates reliably in temperatures ranging from -50°C to 85°C.
The MKP386M features a low equivalent series resistance (ESR) of 10 mΩ.
The dimensions of this capacitor are 44 mm in length, 22 mm in width, and 38 mm in height.
This model supports screw mounting with a lead pitch of 28 mm.
It is constructed with a plastic case for durability and insulation.
This capacitor complies with IEC 60384-17 standards, ensuring quality and safety.
The lead diameter is 0.8 mm, and the lead length is 6 mm.
It is ideal for applications including photovoltaic systems, wind inverters, motor drives, and frequency converters.
The MKP386M has a pin count of 2.
This capacitor is manufactured in Portugal.
