DiodesZetex Silicon Junction Switching Diode, Single, 3 A, 2-Pin, 1000 V, Surface Mount SMC RS3M-13-F
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 2.3mm |
| Length | 7.11mm |
| Model | RS3M-13-F |
| Width | 6.22mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SMC |
| Sub Type | Silicon Junction |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Diode Configuration | Single |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 1.3V |
| Peak Reverse Recovery Time trr | 500ns |
| Maximum Forward Current If | 3A |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 1000V |
Key Features
- This diode features a single silicon junction configuration for efficient switching performance.
- The SMC package offers compact surface mounting with 2 pins.
- Maximum forward voltage drop is 1.3 V under load.
- It supports high non-repetitive surge current up to 100 A.
- Operating temperature ranges from -65°C to 150°C ensuring reliability under harsh conditions.
- Peak reverse recovery time is 500 ns allowing fast switching applications.
- Its dimensions are 7.11 mm length, 6.22 mm width, and 2.3 mm height.
- This diode does not conform to automotive standards.
Product Description
DiodesZetex RS3M-13-F is a silicon junction, single Switching Diode designed for demanding industrial and electronic applications requiring high forward current handling and high voltage blocking capability. Featuring a robust SMC surface mount package, this device ensures compact installation on printed circuit boards while providing reliable electrical performance.
With a maximum forward current of 3 A and a peak repetitive reverse voltage of 1000 V, it is suitable for various switching, rectification, and protection circuits in power management, industrial controls, and power supplies. The diode delivers a low forward voltage drop of 1.3 V which enhances efficiency and minimizes power loss during conduction.
The peak non-repetitive surge forward current rating of 100 A allows this diode to withstand short-duration current spikes without damage, making it reliable under transient conditions. Its 500 ns peak reverse recovery time supports high-speed switching operations typically needed in modern electronic designs.
Operating reliably over a temperature range from -65°C to 150°C, the RS3M-13-F diode can perform in harsh environments and demanding applications. The compact dimensions of 7.11 mm length, 6.22 mm width, and 2.3 mm height enable space-saving PCB layouts.
Single silicon junction diode for switching applications. Robust SMC surface mount package with 2 pins. Rated for a forward current of 3 A and peak reverse voltage of 1000 V. Fast switching with 500 ns peak reverse recovery time.
Wide operating temperature range of -65°C to 150°C. Low forward voltage drop of 1.3 V improves efficiency. Supports high surge current up to 100 A for transient reliability. Compact size facilitates dense circuit board integration.
This product is ideal for industrial electronics, power supplies, semiconductor switching circuits, and electronic component assemblies where reliable and efficient diode performance is required.
Explore the comprehensive range of DiodesZetex semiconductor components at EnvMart to find solutions tailored to your industrial and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward current rating of this diode is 3 A.
It supports a peak reverse voltage of 1000 V.
The maximum forward voltage drop is 1.3 V under load conditions.
The peak non-repetitive surge forward current rating is 100 A.
The peak reverse recovery time is 500 ns, allowing for fast switching applications.
The dimensions are 7.11 mm in length, 6.22 mm in width, and 2.3 mm in height.
It operates reliably over a temperature range from -65°C to 150°C.
The diode uses a robust SMC surface mount package with 2 pins.
It features a single silicon junction configuration.
This diode is suitable for switching, rectification, and protection circuits in power management and industrial controls.
No, this diode does not conform to automotive standards.
The country of origin for the RS3M-13-F diode is India.
