DiodesZetex Silicon Junction Single Switching Diode, 1 A Forward Current, 100 V SMA Package S1B-13-F

Name: DiodesZetex Silicon Junction Single Switching Diode, 1 A Forward Current, 100 V SMA Package S1B-13-F
Brand: DiodesZetex
SKU: 129715
Price: 0.06 USD
Availability: InStock



Category Switching Diodes Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	2.1mm
Length	4.6mm
Model	S1B-13-F
Width	2.92mm
Mount Type	Surface
Series	S1B
Maximum Operating Temperature	150°C
Package Type	SMA
Sub Type	Silicon Junction
Minimum Operating Temperature	-65°C
Pin Count	2
Diode Configuration	Single
Peak Non-Repetitive Forward Surge Current Ifsm	30A
Maximum Forward Voltage Vf	1.1V
Peak Reverse Recovery Time trr	3ns
Maximum Forward Current If	1A
Maximum Peak Reverse Repetitive Voltage Vrrm	100V

Key Features

This diode has a maximum forward voltage of 1.1 V ensuring efficient current conduction.
Peak reverse recovery time is 3 ns, supporting high-speed switching applications.
Operates reliably within a temperature range of -65°C to 150°C.
Compact package dimensions measuring 4.6 mm length, 2.92 mm width, and 2.1 mm height.
Designed as a single diode with 2 terminals for surface mounting on PCBs.
Capable of handling peak non-repetitive forward surge current up to 30 A.
Suitable for electronics, power supplies, and semiconductor switching applications.

Product Description

DiodesZetex S1B-13-F is a single silicon junction switching diode designed for surface mounting with an SMA package type. It supports a maximum forward current of 1 ampere and can withstand a peak reverse repetitive voltage of 100 volts, making it ideal for semiconductor switching and rectification tasks in electronic circuits.

This diode provides a low forward voltage drop of 1.1 volts, enhancing energy efficiency. The fast peak reverse recovery time of 3 nanoseconds enables it to operate effectively in high-frequency switching scenarios commonly found in industrial power supplies, communication devices, and consumer electronics.

The device is robust, operating reliably over a wide temperature range from -65°C to 150°C, thus suitable for various environmental conditions in industrial and commercial use.

Its compact dimensions (length 4.6 mm, width 2.92 mm, height 2.1 mm) and 2-pin surface mount design facilitate easy PCB integration while saving board space. The diode can handle a peak non-repetitive forward surge current of 30 A, ensuring resilience against transient currents.

Overall, the S1B-13-F is an efficient, durable, and compact silicon junction diode appropriate for switching diode applications within electronics, power, and semiconductor sectors.

This diode has a maximum forward voltage of 1.1 V ensuring efficient current conduction. Peak reverse recovery time is 3 ns, supporting high-speed switching applications. Operates reliably within a temperature range of -65°C to 150°C.

Compact package dimensions measuring 4.6 mm length, 2.92 mm width, and 2.1 mm height. Designed as a single diode with 2 terminals for surface mounting on PCBs. Capable of handling peak non-repetitive forward surge current up to 30 A.

Suitable for electronics, power supplies, and semiconductor switching applications. Explore more DiodesZetex semiconductor products and components on EnvMart for your next industrial or electronic design project.
