onsemi Silicon Junction Series Switching Diode 215 mA 100 V 3-Pin SOT-23 SBAV99LT1G

onsemi SBAV99LT1G is a Silicon Junction switching diode from the Series type, designed for small signal surface mount applications. This diode features a maximum forward current of 215 mA and a peak reverse repetitive voltage of 100 V housed in a compact 3-pin SOT-23 package.

The device provides efficient switching due to its fast peak reverse recovery time of 6 nanoseconds. With a maximum power dissipation rating of 225 mW and a low forward voltage drop of 1.25 V, it delivers reliable performance for protecting circuits and enabling fast switching operations.

The diode supports an operating temperature range from -65°C up to 150°C, making it suitable for industrial electronic components, power and connectors, and discrete semiconductor applications.

Its compact physical dimensions, measuring 3.04 mm in length, 1.4 mm in width, and 1.01 mm in height, suit high-density PCB layouts commonly found in modern electronic devices. This product does not carry automotive standard certifications but is ideal for industrial, manufacturing, electronic assembly, and laboratory testing environments.

Small signal switching diode suitable for surface mount applications. Maximum power dissipation of 225 mW ensures robust operation. Fast peak reverse recovery time of 6 ns improves switching performance. Operates reliably between -65°C and 150°C ambient temperatures.

Low forward voltage of 1.25 V reduces power loss. Compact 3.04 mm length, 1.4 mm width, and 1.01 mm height package dimensions. Supports a peak non-repetitive forward surge current of 500 mA. Non-automotive grade product without specific standards approvals.

Ideal for electronic circuit protection and signal switching industrial applications. Explore more semiconductor and switching diode products at EnvMart for advanced industrial and electronic engineering solutions.
