STMicroelectronics 200 V 3 A Switching Diode 2-Pin Through Hole DO-201AD STTH3R02
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 5.3mm |
| Brand | STMicroelectronics |
| Height | 5.3mm |
| Length | 9.5mm |
| Model | STTH3R02 |
| Width | 5.3mm |
| Mount Type | Through Hole |
| Series | STTH3R02 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-201AD |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 3μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 1.2V |
| Peak Reverse Recovery Time trr | 30ns |
Key Features
- Through hole mount type with a DO-201AD package configuration.
- Single diode configuration optimized for switching applications.
- Maximum forward voltage of 1.2 volts ensures efficient conduction.
- Peak reverse current is 3 microamperes, minimizing leakage.
- Supports a high peak surge current of 75 amps for transient conditions.
- Fast peak reverse recovery time of 30 nanoseconds for quick switching operations.
- Operating temperature range from -65°C to 175°C allowing wide environmental tolerance.
- Compliant with RoHS standards for environmental safety.
Product Description
STMicroelectronics STTH3R02 is a high-performance switching rectifier diode designed for industrial and electronic circuit applications requiring reliable switching capabilities at voltages up to 200 V and currents up to 3 A. It features a through hole mount type in a durable DO-201AD package.
This diode's single configuration and fast switching characteristics with a peak reverse recovery time of only 30 ns make it suitable for use in power supplies, inverters, and electronic converters within industrial automation and manufacturing environments.
Its robust design supports peak non-repetitive forward surge currents up to 75 A and a maximum forward voltage drop of 1.2 V, ensuring efficient performance and minimal energy loss. The diode maintains full performance within a broad temperature range from -65°C to 175°C, suitable for demanding operational conditions including HVAC and automotive electronics not requiring automotive certification.
The compact size with dimensions approximately 9.5 mm length and 5.3 mm diameter allows for easy installation in electronic assemblies. It complies with RoHS directives, ensuring reduced hazardous substances and environmental impact.
Through hole mount type with a DO-201AD package configuration. Single diode configuration optimized for switching applications. Maximum forward voltage of 1.2 volts ensures efficient conduction. Peak reverse current is 3 microamperes, minimizing leakage.
Supports a high peak surge current of 75 amps for transient conditions. Fast peak reverse recovery time of 30 nanoseconds for quick switching operations. Operating temperature range from -65°C to 175°C allowing wide environmental tolerance.
Dimensions approximately 9.5 mm length and 5.3 mm diameter. Compliant with RoHS standards for environmental safety.
This STMicroelectronics switching diode is ideal for electronic engineers and industrial designers developing reliable and efficient power switching solutions. Discover more products in the Semiconductor and Switching Diodes categories on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 3 A.
This diode has a peak reverse repetitive voltage rating of 200 V.
It comes in a DO-201AD package configuration, suitable for through hole mounting.
The diode supports a peak non-repetitive forward surge current of 75 A.
The maximum forward voltage drop for this diode is 1.2 V.
It has a fast peak reverse recovery time of 30 nanoseconds.
The operating temperature range is from -65°C to 175°C.
The diameter of this model is approximately 5.3 mm.
The minimum operating temperature for this diode is -65°C.
Yes, it is compliant with RoHS standards for environmental safety.
This model features a single diode configuration optimized for switching applications.
The peak reverse current is 3 microamperes (3 μA), minimizing leakage.
