Samtec Right Angle Through Hole Shrouded PCB Header 40 Contacts 2 mm Pitch 3.2A Current LS2-120-01-L-D-RA1

Samtec LS2-120-01-L-D-RA1 Right Angle Through Hole Shrouded PCB Header is designed for high-performance board-to-board electronic connectivity. It provides 40 male contacts arranged in two rows with a precise 2 mm pitch, suitable for compact and dense PCB assemblies. The housing is made from Liquid Crystal Polymer, offering excellent thermal stability and mechanical strength for durable applications.

This PCB header supports a current capacity of up to 3.2 A per pin, with gold plated phosphor bronze contacts that resist oxidation and ensure reliable conductivity. Its shrouded design prevents accidental misalignment and enhances mating accuracy, critical in industrial and commercial electronics applications.

Rated for operation between -55°C and 125°C, this connector is suitable for a wide range of environments and can handle voltages up to 475 V. The right angle orientation optimizes PCB layout configurations where vertical height clearance is necessary, and the through hole mount type ensures secure and robust mechanical fixing on printed circuit boards.

This product is ideal for Electronics Manufacturing, Industrial Automation, Telecommunications, and other electronic system design applications where reliable board-to-board connectors are essential. The solder termination facilitates established assembly techniques to maintain production efficiency.

Key features include the 40 contact points in 2 rows, a compact 2 mm pitch for dense circuits, durable liquid crystal polymer housing, and gold plated contact surfaces for long-term performance. Operating temperature range and voltage rating provide versatility across demanding conditions.

The connector supports a maximum current of 3.2 A per contact for efficient power transmission. Constructed with a housing of high-performance Liquid Crystal Polymer for enhanced durability. Features a shrouded design ensuring secure mating and prevention of misalignment.

Through hole mounting type ensures firm PCB fixation and mechanical strength. Gold plated phosphor bronze contacts resist corrosion and improve conductivity. Operates in harsh temperature ranges from -55°C to +125°C for industrial reliability.

The 2-row, 40-contact configuration with 2 mm pitch suits compact PCB designs. Designed specifically for board-to-board connection systems requiring right angle orientation. Termination type is solder, facilitating standard assembly processes.

Voltage rating up to 475 V ensures safety in various electrical applications. Explore more electronic components and PCB Header options in the Electronics & Electrical category at EnvMart for your industrial, laboratory, and manufacturing needs.
