onsemi Small Signal NPN Bipolar Junction Transistor, 600 mA, 40 V, 3-Pin TO-92 KSP2222ATA

onsemi KSP2222ATA is a small signal NPN bipolar junction transistor designed for a broad range of electronic applications. Its 600 mA maximum collector current and 40 V collector-emitter voltage provide flexibility for low-voltage switching and amplification tasks.

The TO-92 package with a 3-pin through-hole design allows for convenient mounting on PCBs in various circuit designs. It exhibits a minimum DC gain of 35, assuring consistent performance in amplification circuits.

This transistor offers a maximum power dissipation rating of 625 mW and operates reliably within a temperature range of 0°C to 150°C, making it suitable for industrial and consumer electronic devices.

Compact dimensions of 19.05 mm in height, 5.2 mm in length, and 4.19 mm in width enable efficient use of space in electronic assemblies. The device's robust electrical ratings include a maximum collector-base voltage of 75 V and an emitter-base voltage of 6 V, ensuring durability under typical operating conditions.

Typical uses include signal amplification, switching, and general-purpose electronic circuit applications in industrial, laboratory, and consumer electronics sectors. The transistor supports a maximum DC collector current of 600 mA.

It features a maximum collector-emitter voltage of 40 V suitable for low voltage circuits. The device configuration is single transistor type with NPN polarity. Package type is TO-92 with through-hole mount for easy PCB installation.

It has a minimum current gain (hFE) of 35 ensuring stable amplification. The maximum power dissipation is 625 mW, suitable for small signal applications. Operating temperature range is from 0°C to 150°C providing good thermal stability.

Dimensions are compact with length 5.2 mm, height 19.05 mm, and width 4.19 mm. The transistor provides robust voltage ratings with maximum collector-base voltage of 75 V. Minimum emitter-base voltage rating is 6 V, preventing premature breakdown.
