Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket, 20-Contact, 2 Row, 2.54 mm Pitch, 3A, 500V 61302025721

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket, 20-Contact, 2 Row, 2.54 mm Pitch, 3A, 500V 61302025721

Name: Wurth Elektronik WR-PHD Series Bottom Entry Through Hole PCB Socket, 20-Contact, 2 Row, 2.54 mm Pitch, 3A, 500V 61302025721
Brand: Wurth Elektronik
SKU: 173120
Price: 4.56 USD
Availability: InStock



Category PCB Socket Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	500V
Brand	Wurth Elektronik
Orientation	Bottom Entry
Current	3A
Mount Type	Through Hole
Contact Material	Copper Alloy
Series	WR-PHD
Termination Type	Solder
Maximum Operating Temperature	105°C
Sub Type	PCB Socket
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2.54mm
Standards/Approvals	RoHS
Contact Plating	Gold
Number of Contacts	20
Connector System	Board-to-Board

Key Features

The socket supports a current rating of 3A for robust electrical performance.
It features gold-plated copper alloy contacts to ensure high conductivity and durability.
The 2.54 mm pitch and through-hole mount type facilitate secure solder connections.
Designed for bottom entry orientation, it fits various PCB designs efficiently.
The operating temperature range of -40°C to 105°C supports a wide range of environmental conditions.
It complies with RoHS standards and is UL approved for safety and environmental compliance.
The socket supports up to 25 mating cycles for dependable use in industrial applications.
It withstands voltage up to 500V AC, suitable for demanding electrical environments.

Product Description

Wurth Elektronik 61302025721 is a bottom entry through hole type PCB socket designed for board-to-board connection applications. Featuring 20 gold-plated copper alloy contacts arranged in 2 rows with a 2.54 mm pitch, this socket ensures excellent electrical conductivity and mechanical durability. Rated for 3 amps and able to withstand 500V AC, it supports reliable current and voltage transmission in various industrial and electronic setups.

Its solder termination and through-hole mount type provide robust and secure PCB connections while the bottom entry orientation aids in efficient PCB design layouts. The socket has an operating temperature range from -40°C to 105°C, enabling it to function reliably across harsh environments.

The product meets RoHS compliance and carries UL certification (E323964), guaranteeing adherence to environmental and safety standards. It supports up to 25 mating cycles, ensuring longevity in demanding assembly and manufacturing processes.

Current rating of 3A suitable for moderate power electronics. Gold plating on copper alloy contacts ensures durability and conductivity. 2.54 mm pitch and 2-row configuration for standard PCB layouts. Through hole mount and bottom entry orientation.

RoHS compliant and UL approved for environmental and safety standards. Temperature range from -40°C to 105°C for industrial and commercial applications. Voltage rating up to 500V AC for demanding electrical environments.

Supports 25 mating cycles for extended operational life.

This Wurth Elektronik WR-PHD series PCB Socket is ideally applied in industrial control, embedded systems, instrumentation, communication devices, and other electronic assemblies demanding reliable PCB interconnect solutions.

Explore more reliable and certified PCB connectors and sockets available in the Electronics Components category at EnvMart for your next project.
