TDK SIMID 1210 Unshielded Wirewound Surface Mount Inductor with Ferrite Core 68 μH ±10% 180 mA IDC Q15 B82422H1683K000
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 2.2mm |
| Length | 3.2mm |
| Model | B82422H1683K000 |
| Depth | 2.5mm |
| Packaging | Tape & Reel |
| Series | SIMID |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 180mA |
| Pin Count | 2 |
| Maximum DC Resistance | 3.4Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 10MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Panasonic, DA, 3225 Wire-wound SMD Inductor 68 μH ±5% Wire-Wound 85mA Idc Q | 21Brand: Panasonic |
Key Features
- Inductance precisely controlled at 68 μH ±10% tolerance.
- Maximum DC current rating of 180 mA for reliable operation.
- Package size 1210 with 3.2 mm length, 2.5 mm depth, and 2.2 mm height.
- Wirewound construction with ferrite drum core provides stability.
- Suitable for temperatures from -55°C up to 150°C per AEC-Q200 standard.
- Maximum DC resistance is 3.4 Ω and minimum quality factor is 15.
- Solder termination compatible with JEDEC J STD 020C reflow.
- RoHS compliant and flame retardant encapsulated for safety.
Product Description
The TDK B82422H1683K000 SIMID Series wirewound surface mount inductor offers a compact 1210 package size designed for demanding electronic circuits requiring stable inductance and high current capability. This unshielded component features a ferrite drum core providing excellent magnetic properties and thermal stability.
With an inductance of 68 μH and tolerance of ±10%, it ensures precise performance within various power electronics applications. The inductor can handle a maximum DC current of 180 mA and withstands operating temperatures ranging from -55°C to 150°C, making it ideal for automotive and industrial environments meeting AEC-Q200 standards.
The physical dimensions are 3.2 mm in length, 2.5 mm in depth, and 2.2 mm height. It has a maximum DC resistance of 3.4 Ω, maintaining energy efficiency in DC/DC converters and switch mode power supplies. The inductor construction includes laser-welded windings and solder termination compatible with standard reflow soldering processes per JEDEC J STD 020C.
This component is RoHS compliant and moulded to ensure flame retardant encapsulation suitable for harsh operating conditions. The B82422H1683K000 is manufactured in Hungary under strict quality controls for consistent performance.
Precisely controlled 68 μH inductance with ±10% tolerance. High current rating of 180 mA maximum DC current. Compact 1210 package with dimensions: 3.2 mm length, 2.5 mm depth, 2.2 mm height. Ferrite drum core and wirewound construction ensure performance stability.
Meets automotive standard AEC-Q200 for demanding environments. Maximum DC resistance of 3.4 Ω and minimum quality factor of 15. Compatible with JEDEC J STD 020C reflow soldering. RoHS compliant and flame retardant encapsulated.
This TDK SIMID Surface Mount Inductor is suitable for industrial, automotive, and commercial applications such as power supply filters, DC/DC converters, and switching regulators. Discover more electronics components categories and TDK products at EnvMart for your engineering design and manufacturing needs.
