onsemi Small Signal NPN Transistor 100 mA 45 V 6-Pin SOT-363 Surface Mount BC847BDW1T1G

onsemi BC847BDW1T1G is a small signal NPN transistor designed for efficient switching and amplification in electronic circuits. It features a maximum DC collector current of 100 mA and a collector emitter voltage rating of 45 V, suitable for low voltage applications. The transistor is housed in a compact 6-pin SOT-363 surface mount package, enabling integration into space-constrained PCB layouts.

This device provides a minimum DC current gain (hFE) of 200, ensuring dependable amplification. It is qualified to the automotive standard AEC-Q101, making it suitable for automotive and industrial applications requiring high reliability.

The transistor operates reliably over a broad temperature range from -55°C to 150°C, supporting usage in harsh environments. Its maximum power dissipation is 380 mW and it supports switching frequencies up to 100 MHz, allowing it to handle moderate power and high-frequency signals efficiently.

The physical dimensions of the BC847BDW1T1G transistor are 2.2 mm in length and width, with a height of 1.1 mm, making it ideal for compact electronic designs. The device’s isolated transistor configuration and NPN polarity make it appropriate for many general purpose amplification and switching tasks in industrial, automotive, and consumer electronics.

High maximum DC collector current of 100 mA for efficient switching applications. Collector emitter voltage rating of 45 V suitable for low voltage circuits. Surface mount 6-pin SOT-363 package for compact PCB designs. Minimum DC current gain (hFE) of 200 ensures reliable amplification performance.

Automotive qualified under the AEC-Q101 standard for high reliability. Operating temperature range from -55°C to 150°C for harsh environment use. Maximum power dissipation at 380 mW supports moderate power applications. Maximum transition frequency of 100 MHz allows for high frequency signal processing.

Compact dimensions of 2.2 mm length, 2.2 mm width, 1.1 mm height enable space-saving designs. This transistor is ideal for industrial, laboratory, automotive, and consumer electronics applications where efficient switching and amplification is needed in compact spaces.
