Molex C-Grid III Series Right Angle Through Hole PCB Header, 4 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 90136-2204
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Features a shrouded design to protect contacts during assembly.
- Constructed with polyester housing for durability.
- Male brass contacts plated with gold for reliable conductivity.
- Supports a current of up to 3A and a voltage rating of 350V.
- Suitable for wire-to-board connector systems with one row and 2.54 mm row pitch.
- Operates reliably within a temperature range from -55°C to 125°C.
- Designed for through-hole mounting with solder termination type.
- Tail pin length measures 2.9 mm and mating pin length is 6.75 mm for secure connections.
Product Description
Molex 90136-2204 C-Grid III Series Right Angle Through Hole PCB Header is designed for electronic circuit board applications requiring reliable wire-to-board connections. This PCB header features 4 male contacts arranged in a single shrouded row with a 2.54 mm pitch, facilitating proper alignment and protection in assemblies.
Constructed with a durable polyester housing and brass contacts plated with gold, it ensures excellent electrical performance and longevity. The connector supports a working current of 3A and voltages up to 350V, making it suitable for a wide range of electronic equipment.
The header's right angle orientation and through hole mounting type provide sturdy mechanical and electrical connections, ideal for integration in complex PCBs. Its operating temperature range from -55°C to 125°C allows usage in demanding industrial environments.
The termination uses solder, while the tail pin length of 2.9 mm and mating pin length of 6.75 mm contribute to reliable connector engagement. This product aligns with the Molex C-Grid III series standards and does not have specific certifications or approvals.
Features a shrouded design to protect contacts during assembly. Constructed with polyester housing for durability and insulation. Gold-plated brass contacts ensure high conductivity and corrosion resistance. Rated for 3A current and 350V voltage for electronic system reliability.
Right angle through-hole mount suitable for wire-to-board connection systems. Wide operating temperature range from -55°C to 125°C supports various industrial environments. Tail and mating pin lengths designed for secure, precise connections.
Single row layout with 2.54 mm pitch for standard industry compatibility.
This Molex PCB header is widely used in industrial electronics, automation control, instrumentation, and power distribution systems. It suits applications requiring robust electrical connection and mechanical anchoring. It belongs to the category of PCB Headers, meeting the demands of professional electronics manufacturing and repair.
Explore more high-quality connectors and components in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current of up to 3A and a voltage rating of 350V, making it suitable for various electronic applications.
It features a 2.54 mm pitch and has 4 male contacts arranged in a single row.
The housing is made of polyester, while the contacts are brass plated with gold for reliable conductivity.
It operates reliably within a temperature range from -55°C to 125°C, suitable for demanding industrial environments.
This unit is designed for through-hole mounting with a solder termination type for secure connections.
The tail pin length measures 2.9 mm, and the mating pin length is 6.75 mm, ensuring secure engagement.
It is designed for wire-to-board connector systems, facilitating reliable electrical connections.
This model features a shrouded design, which helps protect the contacts during assembly.
The connector has a right angle orientation, which aids in space-saving design and easier routing on circuit boards.
It belongs to the Molex C-Grid III series, known for its reliable wire-to-board connections.
The country of origin for this product is India.
