Molex C-Grid III Series Straight Through Hole PCB Header 2 Contacts 2.54 mm Pitch 1 Row Shrouded 90136-1102
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Features a straight locking header design compatible with locking housings.
- Connector system is wire-to-board with a straight orientation.
- Housing made of durable polyester for stability and insulation.
- Brass contact material plated with tin for reliable conductivity and corrosion resistance.
- Rated for 3 amperes current at a maximum voltage of 350 volts.
- Operating temperature range from -55°C up to 125°C ensures broad application use.
- Tail pin length is 2.9 mm and mating pin length is 6.75 mm for secure connections.
- Designed for industrial electronic and electrical assembly applications with through hole mount type.
Product Description
Molex 90136-1102 C-Grid III Series Straight Through Hole PCB Header is a high-quality connector designed with 2 contacts arranged in a single row with a 2.54 mm pitch. It features a shrouded housing made of polyester that provides robust insulation and mechanical protection. The contact pins are made of brass with tin plating to ensure excellent conductivity and corrosion resistance.
This PCB header supports a current rating of 3 amperes and a voltage rating of 350 volts, making it suitable for various industrial and electronic applications. It operates reliably across a wide temperature range from -55°C to 125°C, which includes demanding environmental conditions.
Its straight wire-to-board connector system and through hole mount type allow for secure and stable board connections, ideal for manufacturing and assembly of printed circuit boards. The straight locking header design facilitates the use with locking housings to enhance connection security.
The precise 2.9 mm tail pin length and 6.75 mm mating pin length ensure proper mechanical fit and electrical contact. This component is widely used in electronics manufacturing, industrial control systems, automation, and instrumentation.
Features a straight locking header design compatible with locking housings. Connector system is wire-to-board with a straight orientation. Housing made of durable polyester for stability and insulation. Brass contact material plated with tin for reliable conductivity and corrosion resistance.
Rated for 3 amperes current at a maximum voltage of 350 volts. Operating temperature range from -55°C up to 125°C ensures broad application use. Tail pin length is 2.9 mm and mating pin length is 6.75 mm for secure connections.
Designed for industrial electronic and electrical assembly applications with through hole mount type.
This PCB header from Molex is a reliable component suited for various industrial, manufacturing, and electronic assembly applications requiring robust connectors. Explore our full range of PCB Headers and connectors in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header is rated for a current of 3 amperes.
It can handle a maximum voltage of 350 volts.
The operating temperature range is from -55°C to 125°C.
The housing is made of durable polyester, while the contact pins are made of brass with tin plating.
The pitch size of the contacts is 2.54 mm.
This header features 2 contacts arranged in a single row.
It uses a through hole mount type for installation.
The tail pin length is 2.9 mm.
The mating pin length is 6.75 mm.
Yes, it features a straight locking header design that is compatible with locking housings.
It utilizes a wire-to-board connector system with a straight orientation.
This PCB header is manufactured in India.
