Samtec TST Series Right Angle Through Hole PCB Header 10 Contacts 2.54 mm Pitch 2 Row Shrouded TST-105-04-G-D-RA

Free Delivery in India | Lowest Global Shipping Charges

Samtec TST Series Right Angle Through Hole PCB Header 10 Contacts 2.54 mm Pitch 2 Row Shrouded TST-105-04-G-D-RA

Name: Samtec TST Series Right Angle Through Hole PCB Header 10 Contacts 2.54 mm Pitch 2 Row Shrouded TST-105-04-G-D-RA
Brand: Samtec
SKU: 154607
Price: 4.32 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	United States
Voltage	1kV
Brand	Samtec
Orientation	Right Angle
Current	3.4A
Model	TST-105-04-G-D-RA
Mount Type	Through Hole
Housing Material	Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	TST
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board

Key Features

This PCB header features a right angle orientation and a shrouded design for enhanced protection.
It has 10 gold-plated phosphor bronze contacts arranged in two rows with 2.54 mm pitch.
The housing is made of glass filled polyester ensuring durability and electrical insulation.
Supports currents up to 3.4 A and withstands voltages up to 1 kV.
Suitable for operating temperatures ranging from -55°C to 125°C for varied industrial environments.
Contact termination is through soldering, ensuring reliable mechanical and electrical connection.
Ideal for industrial, electronics assembly, manufacturing, and PCB prototyping applications.
Manufactured in the United States, adhering to industry standards without specific certifications.

Product Description

Samtec TST-105-04-G-D-RA is a high-quality right angle through hole PCB header from the TST Series designed to provide reliable and durable board-to-board connection. This component features 10 male contacts arranged in two rows with a 2.54 mm pitch, ideal for printed circuit board assemblies requiring precise positioning and secure electrical connectivity.

The header's housing is crafted from glass filled polyester which offers excellent mechanical strength and reliable electrical insulation. Contacts are made from phosphor bronze, providing good conductivity and corrosion resistance, and are plated with gold for enhanced durability and low contact resistance. Its shrouded design adds a protective barrier against mechanical damage and contamination, beneficial in harsh or industrial environments.

This PCB header supports an operating voltage rating of 1 kV and a maximum current of 3.4 A, suitable for a wide array of industrial and electronic applications. It functions reliably within a wide temperature range from -55°C to 125°C, making it adaptable to varied external conditions.

The product employs solder termination ensuring a secure and permanent connection to the PCB. Its right angle orientation makes it suitable for applications where vertical space is limited or specific board layouts are required.

This PCB header is designed for board-to-board connector systems. Its material composition and plating provide durability and reliable performance. The shrouded design aids in correct circuit board mating and protection.

Supports a broad temperature range suitable for industrial applications. Meets standard mounting and pitch requirements for easy integration. Manufactured to precision in the United States with rigorous quality controls.

Ideal for use in electronics manufacturing, prototyping, and repair.

Customers can rely on Samtec's reputation for high-quality electronic interconnect solutions. Explore more options within the PCB Headers category for compatible products and accessories available through EnvMart.
