Samtec PCB Header IPBT Series Straight Surface, 20 Contacts, 4.19 mm Pitch, 2 Row, Shrouded IPBT-110-H2-T-D-GP
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Model | IPBT-110-H2-T-D-GP |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | IPBT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 4.19mm |
| Contact Plating | Gold or Tin |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
Key Features
- The housing is made of durable Liquid Crystal Polymer for high performance.
- Contacts are fabricated from copper alloy with gold or tin plating ensuring reliable connectivity.
- Designed for board-to-board connection systems in electronic assemblies.
- Operates efficiently in temperatures ranging from -55°C to 125°C.
- Includes a polarized design option and supports solder termination for robust mounting.
- Male contact gender with rugged, shrouded construction for safety and durability.
- Suitable for industrial, electronic device manufacturing, and prototyping applications.
Product Description
Samtec IPBT-110-H2-T-D-GP PCB Header from the IPBT Series is a high-quality straight orientation, surface mount connector designed for board-to-board applications. It features 20 male contacts arranged in 2 rows with a 4.19 mm pitch and shrouded housing constructed from Liquid Crystal Polymer ensuring excellent mechanical strength and electrical insulation.
The contacts are made from a copper alloy and plated with gold or tin for superior conductivity and corrosion resistance. This header operates reliably within a broad temperature range from -55°C to 125°C, making it suitable for demanding industrial environments.
The header offers options for optional polarized guide post holes and accommodates solder termination styles enabling secure and durable PCB mounting. The shrouded design protects the contacts from damage and accidental short circuits, enhancing device safety.
Applications for this PCB header include electronic component manufacturing, industrial control units, telecommunications equipment, and various laboratory and commercial electronic assemblies where reliable and robust PCB interconnections are critical.
The housing features high-performance Liquid Crystal Polymer for stability and durability. Contacts are copper alloy with gold or tin plating to ensure lasting electrical integrity. Shrouded construction provides enhanced protection against mechanical and environmental stress.
Operating temperature range from -55°C to 125°C allows use in diverse industrial conditions. Designed for board-to-board surface mounting with solder termination type. Ideal for use in electronic manufacturing, industrial automation, and testing equipment.
Explore more PCB Headers and connectors at EnvMart to find compatible components for your electronic design and manufacturing requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB header is 4.19 mm.
The maximum operating temperature for the IPBT-110-H2-T-D-GP is 125°C.
This model features 20 male contacts arranged in 2 rows.
The contacts are made from copper alloy and are plated with either gold or tin to ensure reliable connectivity.
It supports solder termination for robust mounting on PCBs.
The housing is constructed from Liquid Crystal Polymer, providing high performance and durability.
This PCB header is suitable for electronic component manufacturing, industrial control units, telecommunications equipment, and various laboratory and commercial electronic assemblies.
Yes, this model features a shrouded design which protects the contacts from damage and accidental short circuits.
The minimum operating temperature for the IPBT-110-H2-T-D-GP is -55°C.
It is designed for board-to-board connection systems in electronic assemblies.
This PCB header has 2 rows of contacts.
The country of origin for this PCB header is India.
