Wurth Elektronik WE-TPC 1028 Shielded Wirewound Surface Mount Inductor with Ferrite Core 1 μH ±30% 8 A DC 744065001
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 2.8mm |
| Length | 10mm |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 1μH |
| Package/Case | 1028 |
| Maximum DC Current | 8A |
| Maximum DC Resistance | 6.5mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| RoHS, REACH, JEDEC JS709B, IPC/JEDEC J-STD-020E, IEC 61249-2-21, IEC 60286-3 | 2013 |
Key Features
- Compact 1028 package with tape and reel packaging for automated assembly.
- Magnetically shielded design to minimize leakage fields and EMI.
- Operating temperature range from -40°C to 125°C suitable for automotive applications.
- Low maximum DC resistance of 6.5 mΩ reducing power loss.
- Compliant with automotive standard AEC-Q200, RoHS, and REACH directives.
- Maximum self-resonant frequency of 100 MHz for efficient high-frequency operation.
- Flat wirewound construction for high current capability and reliability.
- Ideal for portable power devices, DC/DC converters, embedded PCs, and mobile data gathering equipment.
Product Description
Wurth Elektronik model 744065001 is a 1028 package shielded wirewound surface mount inductor featuring a ferrite core, with an inductance of 1 μH and a tolerance of ±30%. Rated for a maximum DC current of 8 A, it is designed to operate effectively within a temperature range of - 40°C to 125°C, making it suitable for demanding industrial and automotive applications.
This inductor’s construction includes magnetic shielding to reduce electromagnetic interference and leakage fields, ensuring stable and efficient performance in high-frequency circuits up to 100 MHz self-resonant frequency. The low maximum DC resistance of 6.5 mΩ contributes to minimal power loss and improved energy efficiency.
Compliant with key industry standards such as AEC-Q200 for automotive reliability, RoHS, REACH, JEDEC JS709B, and IPC/JEDEC J-STD-020E, this component meets stringent quality and environmental requirements. Packaged in tape and reel for seamless integration into automated PCB assembly processes, the WE-TPC series is ideal for portable power applications including PDAs, digital cameras, PCMCIA cards, embedded PCs, and mobile data acquisition systems.
Compact 1028 package size measuring 10 mm length, 10 mm depth, and 2.8 mm height. Wirewound design ensuring high current capacity and robustness. Flat profile suitable for space-constrained electronic designs. Core made from ferrite material for improved inductance stability.
Termination style optimized for surface mount technology. Suitable for industrial, automotive, laboratory, and telemetric equipment.
This Wurth Elektronik inductor is a reliable choice for engineers seeking a high-current, shielded inductor with excellent thermal and electrical characteristics for advanced electronic applications.
Explore more components in the Surface Mount Inductors category on EnvMart for complementary passive components and design solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 1 μH with a tolerance of ±30%.
It is rated for a maximum DC current of 8 A.
The operating temperature range is from -40°C to +125°C.
The maximum self-resonant frequency is 100 MHz, allowing for efficient high-frequency operation.
The maximum DC resistance is 6.5 mΩ, which helps reduce power loss.
This inductor is packaged in a compact 1028 size, measuring 10 mm in length, 10 mm in depth, and 2.8 mm in height.
It features a wirewound construction, which provides high current capability and reliability.
Yes, it is compliant with automotive standard AEC-Q200, as well as RoHS, REACH, and other environmental directives.
The termination style is optimized for surface mount technology.
This model is suitable for applications such as portable power devices, DC/DC converters, and embedded PCs.
It is packaged in tape and reel format, facilitating automated assembly processes.
The core material is ferrite, which contributes to improved inductance stability.
