Wurth Elektronik 0.5 mm Pitch 20 Way Straight Male FPC Connector Solder Pin 68712014022

Wurth Elektronik 68712014022 FPC Connector is a 0.5 mm pitch 20 way straight male connector designed for high precision wire-to-board applications. Featuring a solder pin termination type with surface mount technology, the connector ensures reliable and secure electrical connections suitable for industrial, electronic, and manufacturing environments.

Constructed from phosphor bronze contacts with tin over nickel plating, and housed in flame-retardant liquid crystal polymer, it guarantees durability and compliance with UL94-V0 flammability standards. The connector's Zero Insertion Force (ZIF) locking mechanism simplifies the mating process while maintaining secure positioning.

Operating temperatures range from -25°C to 85°C, making this connector suitable for various climatic conditions. It supports a current rating of 500 mA and a voltage rating of 50 V, performing reliably in low power signal transmissions.

This Wurth FPC connector is compatible with compact electronic assemblies where space constraints exist, providing a horizontal top contact configuration with a single row of 20 contacts spaced at 0.5 mm pitch. It is capable of enduring 25 mating cycles, supporting robust cycle life for prototyping and production.

This connector supports a 0.5 mm pitch spacing for compact electronic applications. It features 20 contacts made from phosphor bronze material ensuring optimal conductivity. The housing is made of durable liquid crystal polymer, suitable for industrial environments.

Designed with surface mount for easy PCB installation and straight orientation for versatility. Zero Insertion Force (ZIF) mechanism with locking ensures secure connections and ease of use. Rated for a maximum current of 500 mA and voltage of 50 V for low power electronics.

Contact plating uses tin over nickel providing corrosion resistance and reliable signal transmission. Operational temperature range from -25°C to 85°C suits diverse manufacturing conditions. Supports up to 25 mating cycles making it durable for repeated assembly and disassembly.

Compact design with top contact position enables use in space-constrained electronic equipment.

Widely used in industrial electronics, manufacturing, and electronic device assembly, this connector provides consistent performance in high-density and precision applications. The product is ideal for designers requiring reliable wire-to-board connections with space efficiency.

EnvMart offers this Wurth Elektronik FPC Connector as part of its extensive range of electronic components, enabling professional engineers and manufacturers to source quality parts for diverse projects.
