Wurth Elektronik 0.5 mm Pitch 45 Way Horizontal Male FPC Connector Surface Mount 68714514522

Wurth Elektronik 68714514522 is a 0.5 mm pitch 45 way horizontal male FPC connector designed for surface mount applications. This connector is engineered to provide reliable and compact PCB connections typical in electronic components and power connectors segments.

Crafted with phosphor bronze contacts and tin over nickel plating, it offers excellent electrical performance and corrosion resistance, ensuring long-term durability in demanding industrial environments. The housing material is liquid crystal polymer, giving high temperature and mechanical resistance.

This connector features a Zero Insertion Force (ZIF) mechanism for easy cable insertion and removal, reducing wear and tear during assembly and maintenance. The locking mechanism provides secure mating, preventing accidental disconnection.

Rated for 250V AC and 500mA current, it suits a range of electronic, HVAC, and manufacturing applications requiring precise and reliable FPC connections. Operating temperature range is from -25°C to 85°C, suitable for various operational environments.

Installation is simplified with surface mount termination on the bottom contact position in a horizontal orientation, making it compatible with dense PCB layouts and automated assembly.

Note that the solder profile must comply with Wurth Elektronik's technical specification to maintain warranty, and cleaning by washing is not recommended to avoid damage. Cleaning should avoid harsh agents and mechanical force to preserve connector integrity.

Features 45 contacts with a 0.5 mm pitch. Phosphor bronze contact material with tin over nickel plating. Surface mount termination, bottom contact position. Zero Insertion Force (ZIF) insertion mechanism. Operating temperature range of -25°C to 85°C.

250V AC voltage and 500mA current rating. Horizontal orientation with locking mechanism. Housing made from liquid crystal polymer. This product is ideal for electronics manufacturing, industrial systems, laboratory equipment, and other applications requiring robust and compact FPC connectors.
