Wurth Elektronik 0.5 mm Pitch 50 Way Straight Male FPC Connector, Solder Pin 68715014522

Wurth Elektronik 68715014522 is a 0.5 mm pitch 50 way straight male FPC Connector designed for wire-to-board applications, providing compact and reliable electrical interconnection.

This male connector features phosphor bronze contacts with tin over nickel plating, offering low contact resistance and excellent corrosion resistance. The connector's surface mount technology (SMT) with bottom contact orientation allows for a low profile layout suitable for space-constrained PCB designs.

A zero insertion force (ZIF) mechanism with locking ensures ease of assembly and reduces mechanical stress on contacts, enhancing connector lifespan through up to 25 mating cycles.

Manufactured using liquid crystal polymer housing certified to UL94-V0 flammability standard, this connector is both durable and flame resistant, operating reliably within a temperature range of -25°C to 85°C.

Features 50 contacts with 0.5 mm pitch for high-density connections. Phosphor bronze contact material ensures excellent electrical performance. Current rating is 500mA and voltage rating is 50V, suitable for low power electronics.

Surface mount and straight orientation design simplifies PCB integration. Zero Insertion Force (ZIF) with locking mechanism protects contacts during assembly. Tin over nickel contact plating for corrosion resistance and durability.

Liquid crystal polymer housing meets UL94-V0 flammability standard. Rated for operation between -25°C and 85°C ambient temperature. Up to 25 mating cycles for reliable long-term use. This connector is ideal for electronics manufacturing, PCB assembly, and compact consumer electronics requiring precise and reliable FPC connections.

Explore more components from Wurth Elektronik and discover high-quality connectors designed for demanding industrial applications on EnvMart.
