Hirose 52 Series Right Angle PCB FPC Connector, 3 Contacts, 0.8 mm Pitch, 1 Row DF52-3S-0.8H(21)

Hirose DF52-3S-0.8H(21) is a high-quality Right Angle PCB FPC Connector from the 52 Series, featuring 3 female contacts with a 0.8 mm pitch, designed specifically for PCB mounting applications. It provides a small, robust wire-to-board connection solution primarily used in electronic components and power connector assemblies.

The connector's compact dimensions of 1.75 mm height and 4.1 mm depth make it suitable for space-constrained installations. It supports current ratings up to 2.5 Amps when used with AWG#28 wire, ensuring reliable electrical performance.

The housing is made of polyamide material, offering halogen-free and durable properties ideal for industrial environments. The contact parts are manufactured from copper alloy and plated with tin to enhance conductivity and resist corrosion. Surface mount termination enables efficient PCB assembly.

Designed with a robust box-shaped crimp contact, this connector prevents deformation enhancing long-term durability. Compatible with cable jackets ranging from 0.5 to 0.6 mm outer diameter (AWG#32 to 28), it supports secure and stable connections. The operating temperature range from -40°C to 85°C makes it suitable for diverse conditions in laboratories, manufacturing, electronic assembly, and control systems.

Hirose 52 Series connectors do not come with specific standards or approvals but maintain stringent quality suitable for commercial and industrial use. The right-angle orientation facilitates flexible PCB layout and cable management designs.

Compact wire-to-board connector with small footprint and right-angle orientation. Supports up to 2.5 Amps current with compatible wire gauge. Durable polyamide housing with halogen-free compliance. Tin-plated copper alloy contacts for reliable electrical joints.

Surface mount termination compatible with standard PCB soldering methods. Wide operating temperature range for industrial and commercial applications. Robust box shape crimp contact design minimizes deformation risks.

The Hirose DF52-3S-0.8H(21) connector is ideal for integration in electronic component manufacturing, PCB assembly, power connector systems, and other industrial control and instrumentation applications. It is commonly used where a reliable and compact FPC connection is required with right-angle PCB interface.
