onsemi 100 V 8 A Surface Mount Schottky Diode 3-Pin TO-263 Package MBRB8H100T4G

onsemi MBRB8H100T4G is a Schottky barrier diode designed for efficient low voltage, high-frequency rectification in surface mount technology. Its 3-pin TO-263 package makes it suitable for compact applications where size and weight are important factors.

This diode supports a maximum continuous forward current of 8 A with a peak reverse repetitive voltage of 100 V. Featuring a low maximum forward voltage of 0.71 V, it offers excellent efficiency and reduced power losses in industrial and automotive electronic circuits.

The diode operates across a wide temperature range from -65°C to 175°C, making it excellent for demanding environments including automotive applications, as it is qualified to AEC-Q101 standards. The epoxy moulded case and Pb-free design support automated board assembly and compliance with environmental regulations.

With dimensions of 10.29 mm length, 9.65 mm width, and 4.83 mm height, the device provides a lightweight solution weighing just 11.7 mg, ideal for weight-sensitive electronics.

Key features of the MBRB8H100T4G include a single diode configuration with a 3-pin design suitable for polarity protection, freewheeling diodes, and high frequency power rectifying circuits. It withstands peak non-repetitive forward surge currents up to 250 A, protecting circuits from transient surge events.

This diode supports a maximum continuous forward current of 8 A. It features a peak reverse repetitive voltage rating of 100 V suitable for low voltage high-frequency rectification. The maximum forward voltage drop is 0.71 V ensuring efficient power use.

Operating temperature ranges from -65°C to 175°C allowing for versatile industrial applications. The device complies with the automotive standard AEC-Q101 ensuring reliability in automotive environments. Its compact dimensions are length 10.29 mm, width 9.65 mm, and height 4.83 mm for space-sensitive circuit boards.

Peak surge current capability is 250 A for transient events. Epoxy moulded case with Pb-free composition enables automated board assembly and meets environmental guidelines. The package weighs approximately 11.7 mg offering lightweight performance benefits.

This diode is ideal for automotive, industrial, laboratory, manufacturing, and power supply applications requiring high-speed switching, low forward voltage drop, and robustness under surge conditions.
