Molex 1.25 mm Pitch 16 Way Right Angle Female FPC Connector, Through Hole Solder Termination 39-53-2164
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 200V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | 5597 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Sub Type | Easy-On FFC/FPC Connector |
| Minimum Operating Temperature | -20°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Tin Bismuth over Nickel |
| Number of Contacts | 16 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
Key Features
- Features a space-saving design suitable for compact electronic assemblies.
- Utilizes a Zero Insertion Force (ZIF) slide type actuator for easy insertion and secure connection.
- Constructed with phosphor bronze contacts plated with tin bismuth over nickel for durability.
- Through hole mounting type with solder termination ensures robust PCB fixing.
- Supports a current rating of 1A and operates up to 200V.
- Operates reliably in temperatures from -20°C to 80°C.
- Includes a locking mechanism for secure cable retention.
- Housing made from durable polybutylene terephthalate material.
Product Description
Molex 39-53-2164 is a 16 contact, 1.25 mm pitch female FPC connector from the 5597 series featuring a right angle orientation and solder termination. This ZIF (Zero Insertion Force) connector allows easy insertion of flexible printed circuits with minimal wear, making it suitable for high cycling applications.
The connector's slide type actuator ensures a secure and reliable connection to the FPC, while its space-saving design is ideal for use in tight packaging environments found in automotive electronic assemblies and other industrial electronic equipment.
Constructed from phosphor bronze contacts with tin bismuth over nickel plating, the connector offers durability and reliable connectivity. The housing is made from polybutylene terephthalate, providing robustness and rated for operation between -20°C and 80°C. It supports a current rating of 1A and a voltage rating of 200V.
This through-hole mount connector has a locking mechanism to prevent accidental disconnection and features staggered solder tails to improve mounting stability on the PCB. The connector is a single row with 16 contacts, conforming to no formal approvals but engineered for reliable industrial and automotive electronic applications.
Space-saving design for compact assemblies. Zero Insertion Force slide actuator minimizes wear. Female connector gender and right angle orientation. Durable phosphor bronze contacts with tin bismuth over nickel plating. Operating temperature range from -20°C to 80°C.
Through hole solder termination for secure PCB attachment. Locking mechanism for secure FPC retention. Polybutylene terephthalate housing material for durability.
This Molex 5597 series FPC Connector is suitable for diverse industrial electronics, automotive applications, and compact device assemblies. It offers reliable electrical performance and mechanical retention ensuring lasting usage in demanding environments.
Explore more connectors and electronic components for your design projects at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 1A.
The maximum operating temperature is 80°C.
This connector features solder termination for secure PCB attachment.
The pitch size is 1.25 mm.
It has 16 contacts.
The housing is made from polybutylene terephthalate.
This connector has a right angle orientation.
It supports through hole mounting.
The minimum operating temperature is -20°C.
The contacts are made from phosphor bronze plated with tin bismuth over nickel.
Yes, it includes a locking mechanism for secure cable retention.
This connector belongs to the Molex 5597 series.
