Molex PCB Socket Vertical Surface Mount 2-Contact 1 Row 1.5 mm Pitch 100V 2A 502584-0260
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 100V |
| Brand | Molex |
| Orientation | Vertical |
| Current | 2A |
| Mount Type | Surface |
| Contact Material | Copper Alloy |
| Series | 502584 |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Sub Type | Wire-to-Board |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.5mm |
| Standards/Approvals | EU RoHS China RoHS Compliant Per - D(2021)4569-DC |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Connector System | Wire-to-Board |
| Stacking Height | 9.7mm |
Key Features
- Designed for a maximum voltage rating of 100 V and current rating of 2 A.
- Constructed with copper alloy contacts plated with tin for reliable connectivity.
- Features a stacking height of 9.7 mm suitable for compact PCB applications.
- Operates reliably within a temperature range of -40°C to 105°C.
- Beige colored body with a male contact gender design for keyed mating.
- Fully compliant with EU and China RoHS directives for environmental safety.
- Suitable for wire-to-board applications requiring secure PCB mounting.
- Manufactured in Japan ensuring high-quality standards.
Product Description
Molex 502584-0260 is a vertical surface mount PCB socket designed for wire-to-board connections with 2 contacts and a single row at 1.5 mm pitch. It supports electrical applications requiring a maximum of 100 V voltage and 2 A current.
This connector utilizes copper alloy contacts plated with tin, ensuring excellent conductivity and corrosion resistance. The socket features a stacking height of 9.7 mm, making it suitable for compact and densely packed PCB assemblies.
Operating reliably within a temperature range from -40°C to 105°C, this component is ideal for industrial, electronic manufacturing, and prototyping environments. The beige-colored body contributes to easy visual identification and handling.
Compliance with EU RoHS and China RoHS standards guarantees that the product meets international environmental and hazardous substance regulations. The male contact gender ensures proper mating and mechanical retention with compatible connectors.
Manufactured in Japan, the Molex 502584-0260 meets high reliability standards demanded by professional electronic assembly and maintenance industries. Maximum 100 V voltage and 2 A current rating. Copper alloy contact material with tin plating.
Operating temperature from -40°C to +105°C. Stacking height of 9.7 mm for compact PCB integration. Vertical orientation surface mount termination. Compliant with EU and China RoHS standards. Beige colored body and male contact gender.
Ideal for wire-to-board PCB applications. Manufactured in Japan ensuring quality and durability.
This PCB socket is suitable for use in Electronic Components, Power & Connectors assemblies, and other industrial and commercial applications requiring reliable wire-to-board connections. Explore more PCB Sockets and related components to suit your design requirements on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket has a maximum voltage rating of 100 V and a current rating of 2 A.
The stacking height of this model is 9.7 mm, making it suitable for compact PCB applications.
It operates reliably within a temperature range of -40°C to 105°C.
This model utilizes a surface mount termination type for installation on PCBs.
The contacts are constructed from copper alloy and are plated with tin for enhanced conductivity and corrosion resistance.
Yes, it is compliant with EU RoHS and China RoHS standards, ensuring it meets international environmental regulations.
This PCB socket features 2 contacts in a single row configuration.
This model has a vertical orientation for surface mount termination.
The contact gender is male, designed for keyed mating with compatible connectors.
This PCB socket is manufactured in Japan, ensuring high quality standards.
It is suitable for wire-to-board applications requiring secure PCB mounting, commonly used in electronic manufacturing and prototyping.
The pitch size of the contacts is 1.5 mm.
