Wolfspeed High Voltage Silicon Carbide Schottky Diode 1200 V 88 A TO-247 Package C4D30120D

Wolfspeed C4D30120D is a high voltage silicon carbide (SiC) Schottky diode designed for advanced power electronics applications. This discrete semiconductor device supports a continuous forward current of 88 amperes and a peak reverse repetitive voltage rating of 1200 volts, making it suitable for demanding high voltage conditions.

The diode comes in a robust TO-247 through-hole package with three pins configured in a common cathode arrangement, providing reliable electrical connections and excellent thermal performance for power conversion devices.

This Wolfspeed SiC diode features an exceptionally low forward voltage drop of 3 volts and minimal peak reverse current, which contributes to improved efficiency and reduced heat generation within switching power supplies, power factor correction (PFC) boost circuits, and high-speed inverter systems.

Operating temperature ranges from -55°C to 175°C ensure performance stability under harsh industrial and electronic environments. The diode's peak non-repetitive forward surge current rating of 100 amperes supports transient conditions frequently encountered in power electronics switching.

With dimensions of 16.13 mm length, 5.21 mm width, and 21.1 mm height, this component balances compact size with high power capacity, suitable for integration into power modules and electronic assemblies.

Through-hole TO-247 package for superior heat dissipation and ease of mounting. 1200 V voltage rating suitable for high voltage applications. 88 A maximum continuous forward current supports high load currents. Low forward voltage and zero reverse recovery current optimize switching efficiency.

Temperature-independent switching behavior enhances reliability in fluctuating conditions. Positive temperature coefficient forward voltage reduces risk of thermal runaway. Applicable in industrial power supplies, electric vehicle chargers, and renewable energy inverters.

This product is a vital component in power and electronic circuits where efficiency, reliability, and thermal performance are critical. Wolfspeed's SiC Schottky diodes are designed to improve the performance of modern hard-switching applications, reducing heat sink requirements and achieving higher switching frequencies for advanced power management.
