DiodesZetex 400 V 1 A Fast Recovery Diode Surface Mount DO-214AC RS1G-13-F

The DiodesZetex RS1G-13-F is a high-performance fast recovery diode tailored for surface mount technology with a DO-214AC package type, designed specifically to meet the needs of modern semiconductor applications requiring fast switching and efficient conduction.

This diode is rated for a maximum continuous forward current of 1 ampere and can withstand peak reverse repetitive voltages up to 400 volts, making it highly suitable for power rectification and protection in industrial electronics and consumer devices.

The device features a peak reverse recovery time of only 150 nanoseconds, significantly reducing switching losses and improving circuit efficiency. Its low maximum forward voltage drop of 1.3 volts helps minimize power dissipation.

With compact dimensions measuring 4.6 mm in length, 2.92 mm in width, and 2.1 mm in height, the RS1G-13-F is compatible with dense PCB layouts, supporting modern miniaturized electronics.

The diode maintains operational stability across a wide temperature range from minus 65 degrees Celsius to 150 degrees Celsius, allowing reliable performance in demanding environmental conditions, including industrial and automotive-grade electronics (though it is not certified to automotive standards).

The peak non-repetitive forward surge current rating of 30 amperes permits handling of transient overloads typically encountered during power cycles or fault conditions. Its 2-pin single configuration ensures straightforward integration into rectifier circuits, switching power supplies, and other fast recovery diode applications.

This product finds extensive use in various industrial, manufacturing, and power electronics domains where fast switching and durability are critical. Explore the full range of Schottky diodes and rectifiers at EnvMart for your semiconductor needs.

Maximum continuous forward current of 1 A ensures reliable operation under load. Peak reverse repetitive voltage of 400 V protects against voltage spikes. Fast recovery time of 150 ns reduces switching losses. Compact DO-214AC surface mount package for efficient PCB assembly.

Wide operating temperature range from -65°C to 150°C for diverse environments. Low forward voltage drop of 1.3 V minimizes power dissipation. Supports high surge currents up to 30 A for transient conditions. 2-pin single diode configuration suitable for rectifier circuits.

Ideal for industrial and semiconductor applications requiring fast switching diodes.
