Wurth Elektronik WE-TPC 8020 Shielded Wirewound Surface Mount Inductor 820 nH ±30% 6 A IDC 74407000082

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WE-TPC 8020 Shielded Wirewound Surface Mount Inductor 820 nH ±30% 6 A IDC 74407000082

Name: Wurth Elektronik WE-TPC 8020 Shielded Wirewound Surface Mount Inductor 820 nH ±30% 6 A IDC 74407000082
Brand: Wurth Elektronik
SKU: 106635
Price: 1.37 USD
Availability: InStock



Category Surface Mount Inductors Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Operating Temperature	- 40 to +125°C
Height	8mm
Length	8mm
Depth	1.8mm
Packaging	Tape & Reel
Series	WE-TPC
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	820nH
Package/Case	8020
Maximum DC Current	6A
Maximum DC Resistance	11mΩ
Inductance Tolerance	±30 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	200MHz
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200
Standards/ApprovalsIEC 60286-3	2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS
IEC 60286-3	2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS

Key Features

The inductor features a compact 8020 package size with 8 mm length and height, and 1.8 mm depth.
Constructed with a ferrite core and wirewound inductor construction ensuring stable and reliable performance.
Offers magnetic shielding to reduce leakage fields, suitable for high current applications.
Meets automotive AEC-Q200 standard ensuring quality and reliability in automotive environments.
Designed to operate between -40°C and 125°C with a maximum DC resistance of 11 mΩ.
Packaging by Tape & Reel enables efficient insertion and handling in automated assembly lines.

Product Description

Wurth Elektronik 74407000082 is a WE-TPC series shielded wirewound surface mount inductor with a ferrite core providing an inductance of 820 nH with a tolerance of ±30%. This inductor supports a maximum DC current of 6 A, making it suitable for high current and power applications. The compact 8020 package with dimensions of 8 mm length, 8 mm height, and 1.8 mm depth facilitates use in space-constrained PCB layouts.

The magnetic shielding imparts low leakage fields, which is critical in densely populated circuit boards to minimize EMI effects. The ferrite core and wirewound construction offer reliable inductance characteristics with minimal losses, supporting a maximum DC resistance of only 11 mΩ, enhancing efficiency in power circuits.

The component complies with automotive AEC-Q200 standard, assuring robustness in automotive and industrial applications, and satisfies multiple international standards including IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, and RoHS directives, ensuring environmental and safety compliance.

This inductor operates reliably over a temperature range of -40°C to +125°C, supporting a wide range of industrial, automotive, and consumer electronics environments. The tape & reel packaging supports high volume manufacturing with automated pick-and-place machines, improving production efficiency.

Typical applications include portable power solutions such as PDAs, digital cameras, PCMCIA cards, displays, DC/DC converters, embedded PCs, mobile data gathering, and telemetry devices where compact, efficient, and shielded inductors are essential.

The inductor provides a balanced combination of small size and high current capacity. Ferrite core construction enhances magnetic performance and thermal stability. Shielding reduces electromagnetic interference ensuring signal integrity.

Packaging style suits automated assembly improving manufacturing throughput. Multiple certifications ensure compliance with industry standards and regulations. Explore more Wurth Elektronik inductors and electronic components on EnvMart for your industrial and laboratory needs.

Explore more products in our Surface Mount Inductors category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model features an inductance value of 820 nH with a tolerance of ±30%.

It supports a maximum DC current of 6 A, making it suitable for high current applications.

The inductor has dimensions of 8 mm in length, 8 mm in height, and 1.8 mm in depth.

This unit operates reliably within a temperature range of -40°C to +125°C.

It is constructed with a ferrite core, which enhances its magnetic performance.

The inductor is packaged in Tape & Reel format, facilitating efficient handling in automated assembly lines.

It meets the automotive AEC-Q200 standard, ensuring reliability in automotive environments.

The maximum DC resistance is 11 mΩ, which contributes to its efficiency in power circuits.

The maximum self-resonant frequency is 200 MHz, suitable for various applications.

It complies with multiple standards, including IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, along with REACH and RoHS directives.

Typical applications include portable power solutions, DC/DC converters, and embedded PCs, where compact and efficient inductors are essential.

This model features a wirewound construction, which provides stable inductance characteristics with minimal losses.
