onsemi 20 V 1 A Schottky Diode Surface Mount SOD-123 Package MBR120VLSFT1G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 0.9mm |
| Length | 2.9mm |
| Model | MBR120VLSFT1G |
| Width | 1.8mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 125°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 20V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 15mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 45A |
| Maximum Forward Voltage Vf | 340mV |
Key Features
- Compact SOD-123 surface mount package suitable for automated assembly.
- Maximum continuous forward current of 1 ampere ensures reliable conduction.
- Peak repetitive reverse voltage rating of 20 volts for high voltage tolerance.
- Maximum forward voltage drop of 340 millivolts reduces power losses.
- Operating temperature range from -65°C to 125°C supports harsh environments.
- Peak non-repetitive forward surge current up to 45 amperes provides short-term robustness.
- 2-pin single diode configuration for standard Schottky rectification.
- Meets AEC-Q101 automotive standard for automotive reliability.
Product Description
onsemi MBR120VLSFT1G is a high-performance Schottky diode designed for low voltage, high-frequency rectification applications with a maximum continuous forward current of 1 ampere and a peak repetitive reverse voltage of 20 volts. Packaged in a compact SOD-123 surface mount case, it suits automated PCB assembly processes, offering a small form factor measuring approximately 2.9mm length, 1.8mm width, and 0.9mm height.
This diode utilizes the Schottky barrier principle with a metal-semiconductor junction to provide a low forward voltage drop of around 340 millivolts and minimized leakage current at high switching speeds. It is ideal for freewheeling diode roles and polarity protection in power supply circuits, automotive electronics, and industrial equipment requiring efficient power conversion and switching.
The device supports a broad ambient operating temperature range from -65°C to +125°C, making it suitable for demanding industrial and automotive environments. Additionally, it features a peak non-repetitive surge current capacity of 45 amperes for transient robustness.
The MBR120VLSFT1G meets the AEC-Q101 automotive qualification standard, ensuring high reliability and durability in automotive applications. Its lightweight epoxy molded package weighs approximately 11.7 milligrams, contributing to reduced board weight.
Compact SOD-123 surface mount design compatible with automated assembly. Low forward voltage reduces conduction losses improving efficiency. Wide operating temperature range enables use in harsh conditions. Meets automotive AEC-Q101 for reliable automotive deployment.
High surge current capability protects against transient events. Lightweight epoxy molded package construction. Schottky diode suitable for high frequency, low voltage rectification. Used in power supplies, automotive electronics, and industrial equipment.
This onsemi Schottky diode is recommended for industrial, automotive, and commercial power electronics applications requiring efficient, compact rectification solutions. Explore EnvMart's comprehensive semiconductor and diode collection for compatible high-quality components to enhance your electronic designs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the MBR120VLSFT1G is 1 ampere.
This Schottky diode has a peak repetitive reverse voltage rating of 20 volts.
The maximum forward voltage drop is 340 millivolts, which helps reduce power losses.
It operates within a temperature range of -65°C to +125°C, making it suitable for harsh environments.
The MBR120VLSFT1G is packaged in a compact SOD-123 surface mount case.
This model can handle a peak non-repetitive forward surge current of up to 45 amperes.
The diode features a 2-pin single diode configuration.
It meets the AEC-Q101 automotive standard, ensuring reliability for automotive applications.
The dimensions are approximately 2.9mm in length, 1.8mm in width, and 0.9mm in height.
This unit is a Schottky rectifier, suitable for low voltage, high-frequency applications.
The peak reverse current is rated at 15 milliamperes.
It is recommended for use in power supplies, automotive electronics, and industrial equipment requiring efficient rectification solutions.
