onsemi Transistor 500 mA NPN + PNP Dual Bipolar 30 V 6-Pin Surface-Mount SOT-363 Package FFB2227A
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.1mm |
| Length | 3mm |
| Model | FFB2227A |
| Width | 3mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-363 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 6 |
| Maximum Collector Emitter Voltage Vceo | 30V |
| Minimum DC Current Gain hFE | 30 |
| Transistor Polarity | NPN + PNP |
| Maximum Emitter Base Voltage VEBO | 5V |
| Maximum Collector Base Voltage VCBO | 60V |
| Maximum Power Dissipation Pd | 300mW |
| Maximum DC Collector Current Idc | 500mA |
| Transistor Configuration | Isolated |
| Maximum Transition Frequency ft | 100MHz |
Key Features
- Supports a maximum DC collector current of 500 mA.
- Maximum collector-emitter voltage rating is 30 V for robust switching.
- Packaged in a compact 6-pin SOT-363 surface-mount package.
- Features isolated transistor configuration suitable for diverse circuit designs.
- Handles maximum power dissipation of 300 mW for effective thermal management.
- High collector-base voltage of up to 60 V ensures stable operation.
- Maximum transition frequency up to 100 MHz for high-speed switching applications.
- Operating temperature range from -55°C to 150°C for suitability in harsh environments.
Product Description
onsemi FFB2227A transistor is a dual bipolar junction transistor comprising both NPN and PNP types in a single SOT-363 surface-mount package with six pins. Designed with isolated transistor configuration, it offers versatile solutions for switching and amplification in electronic circuits.
This transistor supports a maximum DC collector current of 500 mA and withstands collector-emitter voltages up to 30 V, ensuring robust performance in demanding applications. It also features a collector-base voltage of 60 V and a power dissipation rating of 300 mW, making it suitable for reliable thermal performance in compact designs.
The high transition frequency of 100 MHz allows it to perform efficiently in high-speed switching tasks. Its operating temperature range from -55°C to 150°C supports use in a variety of industrial, commercial, and laboratory environments.
The compact SOT-363 package with dimensions of 3 mm width, 1.1 mm height, and 3 mm length enables installation in dense PCB layouts, making it ideal for modern electronics manufacturing.
Supports maximum collector current of 500 mA. Rated for 30 V collector-emitter voltage. Compact 6-pin SOT-363 surface-mount package. Isolated transistor configuration for circuit versatility. 300 mW maximum power dissipation rating.
High collector-base voltage rating of 60 V. Up to 100 MHz transition frequency for high-speed operation. Wide operating temperature range from -55°C to 150°C. Minimum DC current gain of 30 for efficient amplification. Small physical dimensions suited for compact PCBs.
This onsemi transistor is suitable for electronic component applications in industrial equipment, power supplies, telecommunications, automotive electronics, and consumer devices. Its robust ratings and compact form help designers achieve high performance while saving PCB space.
Explore EnvMart's extensive semiconductor and discrete transistor collections for compatible components and accessories.
Explore more products in our Bipolar Transistors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum DC collector current of 500 mA.
It has a maximum collector-emitter voltage rating of 30 V, ensuring robust performance in demanding applications.
The maximum transition frequency is up to 100 MHz, allowing for high-speed switching applications.
The SOT-363 package has dimensions of 3 mm in length, 3 mm in width, and 1.1 mm in height.
It operates within a temperature range from -55°C to 150°C, making it suitable for various environments.
The maximum power dissipation rating for this transistor is 300 mW, which aids in effective thermal management.
This unit features an isolated transistor configuration, providing versatility for circuit designs.
It has a minimum DC current gain of 30, which is beneficial for efficient amplification.
The maximum collector-base voltage is rated at 60 V, ensuring stable operation.
This transistor is suitable for applications in industrial equipment, power supplies, telecommunications, automotive electronics, and consumer devices.
The SOT-363 package contains 6 pins, facilitating its use in compact PCB layouts.
This model features both NPN and PNP transistor polarities in a single package.
