| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 3mm |
| Model | BAS40-05-7-F |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | BAS40-05 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 200nA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 5ns |
DiodesZetex BAS40-05-7-F is a high-performance 40 V 200 mA surface mount switching diode housed in a 3-pin SOT-23 package, optimized for reliable operation in demanding industrial and automotive electronics applications.
This diode features a common cathode configuration with a maximum continuous forward current rating of 200 mA, making it suitable for low power switching and rectification tasks. Its peak reverse repetitive voltage of 40 V and fast peak reverse recovery time of 5 ns enable efficient operation at high switching frequencies.
The compact 3 mm length, 1.4 mm width, and 1.1 mm height package facilitates dense PCB layouts while maintaining strong thermal performance. The diode supports operation over a wide temperature range from -55°C to 125°C, ensuring stability in harsh environments.
With a maximum forward voltage of 1 V and peak surge current capability of 600 mA, the BAS40-05-7-F diode delivers efficient power handling and transient resilience. It is designed in compliance with the automotive AEC-Q101 standard for strict quality assurance.
This Schottky barrier diode variant from DiodesZetex is ideally used in electronic power supplies, switching regulators, and automotive electronic circuits requiring stable switching characteristics and high reliability.
Features a common cathode diode configuration suitable for switching applications. Rated for maximum continuous forward current of 200 mA and peak reverse repetitive voltage of 40 V. Compact 3 mm length, 1.4 mm width, and 1.1 mm height surface mount package.
Fast peak reverse recovery time of 5 nanoseconds enhancing switching performance. Designed for operation across a wide temperature range from -55°C to 125°C. Peak non-repetitive forward surge current capability of 600 mA supports transient conditions.
Forward voltage drop maximum of 1 V for efficient power use. Manufactured to comply with automotive standard AEC-Q101 ensuring quality and robustness. Ideal for use in industrial electronics, power supplies, and switching regulator circuits.
