| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 1.8mm |
| Model | B0530WS-7-F |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | B0530WS |
| Maximum Operating Temperature | 125°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | FBI |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 500mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 2A |
| Maximum Forward Voltage Vf | 450mV |
DiodesZetex B0530WS-7-F is a high-performance Schottky diode designed for efficient rectification in surface mount technology applications. It features a compact 2-pin SOD-323 package, facilitating easy PCB assembly while maintaining robust electrical properties.
This diode supports a maximum continuous forward current of 500 mA and withstands a peak reverse repetitive voltage of up to 30 V, ideal for power-sensitive electronic circuits. The forward voltage of 450 mV ensures minimal power loss and improved efficiency in power conversion.
Engineered to operate reliably in a wide temperature range from -40°C to 125°C, it is suitable for harsh industrial and automotive environments. Its peak non-repetitive forward surge current rating of 2 A ensures durability under transient load conditions. Additionally, the diode complies with AEC-Q101 automotive standards, reinforcing its quality and reliability for automotive electronics applications.
The diode’s precise dimensions (1.8 mm length, 1.4 mm width, and 1.1 mm height) enable compact circuit design. The peak reverse current of 500 μA indicates low leakage, contributing to stable and efficient circuit performance.
This component is manufactured in China and represents advanced Schottky barrier diode technology with high thermal stability and superior performance compared to standard PN junction diodes.
Compact 2-pin SOD-323 package for surface mounting. Maximum continuous forward current up to 500 mA. Low forward voltage of 450 mV for high efficiency. Wide operating temperature range: -40°C to 125°C. Peak non-repetitive forward surge current of 2 A.
Automotive grade AEC-Q101 compliance. Small physical dimensions supporting compact PCB layout. Low peak reverse current ensuring minimal leakage. Suitable for industrial, automotive, and power electronics. Manufactured with high-quality standards in China.
This Schottky diode is ideal for applications requiring efficient switching and low forward voltage drop in industrial, automotive, and consumer electronic devices. Explore more electronic components on EnvMart for your design and manufacturing needs.
