DiodesZetex Surface Mount Schottky Diode 40 V 1 A DO-214AC Package B140-13-F

DiodesZetex B140-13-F is a surface mount Schottky diode designed for electronic power applications requiring efficient rectification with minimal forward voltage drop. It supports a maximum continuous forward current of 1 ampere and a peak reverse voltage of 40 volts, making it suitable for low voltage power supply circuits.

Its DO-214AC package type offers compact assembly on printed circuit boards within industrial, automotive, and consumer electronics sectors. The diode features a low forward voltage of 500 millivolts to minimise power dissipation and increase overall system efficiency.

Operating over a temperature range from -65°C to 150°C, the diode maintains performance in demanding environments. It complies with the automotive AEC-Q101 standard, ensuring robust reliability under stringent automotive stress conditions.

The device incorporates two pins for electrical connection and supports a peak surge current of 30 amperes, enhancing its capacity to handle transient overloads commonly encountered in power circuits.

Typical applications include power rectification, voltage clamping, and reverse polarity protection in industrial, automotive, laboratory, and commercial electronic systems requiring durable and efficient semiconductor solutions.

This diode features a surface mount type with a DO-214AC package for compact electronic designs. Maximum continuous forward current rating of 1 ampere ensures reliable conduction in circuits. Peak reverse repetitive voltage of 40 volts provides robust blocking capability.

Low maximum forward voltage of 500 millivolts reduces power loss and heat generation. Operating temperature range from -65°C up to 150°C supports harsh industrial environments. Constructed with Schottky rectifier technology delivering high speed switching performance.

Pin count of 2 pins supports simple integration in electronic assemblies. Automotive standard AEC-Q101 certified ensuring suitability for automotive and industrial applications. Small physical dimensions: length 4.6 mm, width 2.92 mm, and height 2.1 mm, ideal for space-constrained PCB layouts.

Peak non-repetitive forward surge current rating of 30 amperes for transient conditions. Explore the Electronics & Electricals category at EnvMart for more semiconductor devices and Schottky diodes tailored to industrial and automotive needs.
