DiodesZetex 80 V 500 mA Switching Diode 6-Pin Surface Mount SC-88 MMBD4448HADW-7-F
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1mm |
| Length | 2.2mm |
| Model | MMBD4448HADW-7-F |
| Width | 1.35mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SC-88 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | FBI |
| Pin Count | 6 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 500mA |
| Peak Reverse Repetitive Voltage Vrrm | 80V |
| Diode Configuration | 2X Common Anode Pair |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 4A |
| Maximum Forward Voltage Vf | 1.25V |
| Peak Reverse Recovery Time trr | 4ns |
Key Features
- Designed for fast switching applications in electronic circuits.
- Surface mount package type SC-88 with compact dimensions.
- Features a 2X common anode pair diode configuration.
- Maximum forward voltage of 1.25 V ensuring efficient conduction.
- Operates reliably between -65°C minimum to 150°C maximum temperature range.
- Peak non-repetitive forward surge current rated at 4 A.
- Fast recovery time of 4 nanoseconds for high-speed switching.
- Complies with automotive standard AEC-Q101 for quality and reliability.
Product Description
DiodesZetex MMBD4448HADW-7-F is a high-performance switching diode designed for fast switching applications within electronic and semiconductor devices. This 6-pin diode features a surface mount SC-88 package type facilitating compact and efficient PCB designs.
The diode supports a maximum continuous forward current of 500 mA and a peak reverse repetitive voltage of 80 V, making it suitable for various power and signal switching roles in industrial, automotive, and consumer electronics.
This device utilizes a 2X common anode pair configuration optimized for efficient diode array applications. The diode's maximum forward voltage is 1.25 V, enabling minimal power loss and improved circuit efficiency.
Operating within a wide temperature range from -65°C to 150°C, the MMBD4448HADW-7-F ensures reliable functioning in demanding environments, including automotive grade applications compliant with AEC-Q101 standards. Its peak non-repetitive forward surge current rating of 4 A provides robustness against transient currents.
Designed with fast reverse recovery time of 4 nanoseconds, this diode supports high-speed switching circuits for industrial automation, power converters, and signal processing systems. The compact physical size, with dimensions approximately 2.2 mm length, 1.35 mm width, and 1.0 mm height, further enhances PCB layout flexibility.
Applications span across industrial electronics, automotive electronics control units, power management modules, and other devices requiring efficient diode switching capabilities.
Designed for fast switching applications in electronic circuits. Surface mount package type SC-88 with compact dimensions. Features a 2X common anode pair diode configuration. Maximum forward voltage of 1.25 V ensuring efficient conduction.
Operates reliably between -65°C minimum to 150°C maximum temperature range. Peak non-repetitive forward surge current rated at 4 A. Fast recovery time of 4 nanoseconds for high-speed switching. Complies with automotive standard AEC-Q101 for quality and reliability.
Pin count of 6 suitable for advanced electronic component integration. Explore our comprehensive selection of semiconductor diodes and Schottky rectifiers for various electronic design requirements on EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the MMBD4448HADW-7-F is 500 mA.
This model has a peak reverse repetitive voltage rating of 80 V.
The maximum forward voltage drop is 1.25 V, ensuring efficient conduction.
It operates reliably within a temperature range of -65°C to 150°C.
The peak reverse recovery time is 4 nanoseconds, suitable for high-speed switching applications.
The diode comes in a surface mount SC-88 package type, which is compact in size.
This model features a pin count of 6, suitable for advanced electronic component integration.
The peak non-repetitive forward surge current is rated at 4 A, providing robustness against transient currents.
It complies with the automotive standard AEC-Q101, ensuring quality and reliability for automotive applications.
The MMBD4448HADW-7-F utilizes a 2X common anode pair diode configuration.
The dimensions of the diode are approximately 2.2 mm in length, 1.35 mm in width, and 1.0 mm in height.
It is suitable for various power and signal switching roles in industrial, automotive, and consumer electronics.
