Molex 1 mm Pitch 20 Way Right Angle Female FPC Connector, Solder, Easy-On ZIF Series 52271-2069
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50, 50V ac |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 500mA |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | 52271 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Sub Type | Easy-On FFC/FPC Connector |
| Minimum Operating Temperature | -20°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 20 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- Features a Zero Insertion Force (ZIF) design allowing repeated cycling with minimal wear.
- Includes a slide type actuator that rotates 30° to facilitate FPC insertion.
- Designed with bottom contacts and gold over nickel plating for reliable electrical performance.
- Constructed of durable nylon housing with phosphor bronze contact material.
- Supports operating temperatures from -20°C to 85°C, suitable for various industrial applications.
- Right angle orientation with solder termination for secure PCB retention and strain relief.
- Rated for 500 mA current and 50V AC voltage, making it suitable for compact electronic assemblies.
- Ideal for automotive, consumer electronics, medical devices, and communications equipment.
Product Description
Molex 52271-2069 is a 1 mm pitch, 20 way right angle female FPC connector with solder termination, designed for surface mount applications in tight packaging environments.
This Easy-On ZIF FPC connector series features a slide type actuator that rotates 30°, providing Zero Insertion Force for securing flat flexible cables with minimal wear and ease of use.
The connector contact material is phosphor bronze plated with gold over nickel, guaranteeing reliable electrical contacts with low insertion force and high durability. Its nylon housing ensures robust mechanical strength.
Rated for a current of 500 mA and voltage of 50V AC, it operates effectively within a temperature range of -20°C to 85°C, making it suitable for demanding industrial, automotive, consumer electronics, medical, and communications applications.
The right angle orientation with bottom contact position includes solder tabs that provide secure PCB retention and strain relief, enhancing mechanical stability during use.
This connector is widely used in automotive navigation systems, digital cameras, home security devices, tablets, notebooks, patient monitors, GPS units, smartphones, and other portable electronics.
Zero insertion force (ZIF) design for minimal wear during repeat cycling. Slide type actuator for easy insertion and reliable connection. Gold over nickel plating improves conductivity and contact reliability. Nylon housing ensures durability and mechanical stability.
Solder tabs provide strong PCB retention and strain relief for long-term stability. Compact 1 mm pitch and 20 contacts maximize space efficiency. Right angle female connector suitable for surface mount applications. Wide operating temperature range enhances usability across various environments.
This Molex 52271 series FPC connector represents a high-quality solution for secure, durable, and efficient flat flexible cable terminations in multiple sectors. Explore our extensive selection of FPC Connectors to find the perfect fit for your electronic assembly needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a 1 mm pitch and has 20 contacts.
The maximum operating temperature for this connector is 85°C.
It uses solder termination, which provides secure PCB retention.
The housing is made of nylon, and the contact material is phosphor bronze with gold over nickel plating.
It is rated for a current of 500 mA and a voltage of 50V AC.
This connector has a right angle orientation, suitable for surface mount applications.
It features a Zero Insertion Force (ZIF) design, allowing for minimal wear during repeated use.
It can operate within a temperature range of -20°C to 85°C.
This connector is suitable for automotive, consumer electronics, medical devices, and communications equipment.
The slide type actuator rotates 30° to facilitate the insertion of flat flexible cables, ensuring a reliable connection.
The contact position is at the bottom, enhancing mechanical stability during use.
The country of origin for this connector is Japan.
