IXYS Thyristor Module SOT-227B, 1600 V, 1.5 kA, 99A, Panel Mount, 4-Pin MCO100-16IO1

Free Delivery in India | Lowest Global Shipping Charges

IXYS Thyristor Module SOT-227B, 1600 V, 1.5 kA, 99A, Panel Mount, 4-Pin MCO100-16IO1

Name: IXYS Thyristor Module SOT-227B, 1600 V, 1.5 kA, 99A, Panel Mount, 4-Pin MCO100-16IO1
Brand: IXYS
SKU: 84817
Price: 53.04 USD
Availability: InStock



Category Thyristor Module Brand IXYS Condition New

Specifications

Country of Origin	India
Brand	IXYS
Height	9.6mm
Length	38.2mm
Model	MCO100-16IO1
Width	25.07mm
Mount Type	Panel
Maximum Operating Temperature	150°C
Package Type	SOT-227B
Pin Count	4
Rated Average On-State Current Irms	99A
Repetitive Peak Reverse Voltage VDRM	1600V
Surge Current Rating	1.5kA
Maximum Gate Trigger Current Igt	100mA
Maximum Holding Current Ih	200mA
Maximum Gate Trigger Voltage Vgt	1.5V
Peak On-State Voltage	1.35V
Repetitive Peak Off-State Current	10mA

Key Features

Designed for high power semiconductor switching applications.
Operates with a repetitive peak reverse voltage of 1600 V and a surge current rating of 1.5 kA.
Rated average on-state current of 99A with a maximum gate trigger current of 100 mA for precise triggering.
Encapsulated module with electrically isolated base plate ensures safe panel mount installation.
Features four-pin SOT-227B package for reliable operation and easy integration into control circuitry.
Suitable for battery chargers, welders, plating equipment, regulated power supplies, and temperature or speed control systems.
Withstands maximum gate trigger voltage of 1.5 V and a maximum operating temperature up to 150°C.
Compact design with 38.2 mm length, 25.07 mm width, and 9.6 mm height.

Product Description

The IXYS MCO100-16IO1 Thyristor Module is engineered for demanding semiconductor switching and power regulation applications, delivering reliable performance across a broad range of industrial settings.

This module features a repetitive peak reverse voltage of 1600 V and a surge current rating of 1.5 kA, enabling efficient handling of high voltages and transient currents. With a rated average on-state current of 99A, this thyristor module is well-suited for continuous operation in circuits requiring robust power control.

The SOT-227B 4-pin encapsulated package ensures electrical isolation and safety during panel mounting. The maximum gate trigger current is 100 mA, allowing for precise actuation. The module’s maximum holding current is 200 mA, maintaining consistent operational stability during switching events. The peak on-state voltage of 1.35 V supports efficient load conduction while minimizing losses.

Its compact physical dimensions - 38.2 mm in length, 25.07 mm in width, and 9.6 mm in height - make integration straightforward into various control boards and power assemblies. The electrically isolated base plate aids in safe installation and enhances system reliability, especially when panel mounted.

Designed for use in battery chargers, welding equipment, plating systems, regulated power supplies, and temperature or speed control circuits, the IXYS MCO100-16IO1 is versatile and robust. It operates up to a maximum temperature of 150°C, ensuring thermal resilience in industrial conditions.

Applications include industrial power switching, laboratory power supplies, manufacturing process controls, motor speed regulation, and commercial energy management setups. The module's technical profile makes it suitable for environments that demand high-current, high-voltage solid-state switching and precision control.

Explore the complete range of IXYS high power thyristor modules within the Thyristor Module category to meet specific industrial power control and semiconductor switching requirements.
