Panasonic EZPV80356MTC Film Capacitor 35F 800V DC ±10% Tolerance Through Hole
Specifications
| Country of Origin | China |
|---|---|
| Brand | Panasonic |
| Height | 51mm |
| Length | 57.5mm |
| Model | EZPV80356MTC |
| Width | 30mm |
| Mount Type | Through Hole |
| Series | EZPV |
| Maximum Operating Temperature | 105°C |
| Tolerance | ±10 % |
| Capacitance | 35F |
| Minimum Operating Temperature | -40°C |
| Lead Length | 4mm |
| Standards/Approvals | RoHS |
| Package/Case | Plastic |
| Pin Count | 4 |
| Rated DC Voltage | 800V dc |
| Lead Pitch | 52.5mm |
| Lead Diameter | 1.2mm |
| Automotive Standard | AEC-Q200 |
| Equivalent Series Resistance ESR | 10.2mΩ |
Key Features
- Metallized polypropylene film capacitor for high-reliability DC applications.
- Large 35F capacitance value for significant energy storage and power conditioning.
- Rated for 800V DC operation, ideal for use in DC filtering and link circuits.
- ±10% capacitance tolerance ensures consistent, precise performance.
- Through hole configuration with 52.5mm lead pitch for secure PCB mounting.
- Automotive standard AEC-Q200 compliance.
- Low Equivalent Series Resistance (10.2mΩ) supports high-efficiency and minimal losses.
- Flame retardant construction and RoHS compliant for enhanced safety and regulatory compliance.
Product Description
The Panasonic EZPV80356MTC Film Capacitor is a high-performance metallized polypropylene component, designed for demanding DC applications where high reliability and safety are essential. With a substantial 35F capacitance and a high rated DC voltage of 800V, this capacitor is well suited for DC filtering, DC-link circuits, renewable energy inverters, and similar power electronic systems requiring substantial energy storage and low losses.
This model features a through hole mounting design with a robust 4-pin construction and a generous 52.5mm lead pitch, ensuring stable insertion in printed circuit boards and superior electrical contact. The capacitor comes with a tight capacitance tolerance of ±10%, offering excellent predictability for engineers and manufacturers assembling high-reliability circuits.
Benefitting from low Equivalent Series Resistance (only 10.2 milliohms), the EZPV80356MTC minimizes power dissipation and heat generation, making it ideal for continuous operation in industrial and renewable energy systems. The device withstands a wide operating temperature range from -40°C to +105°C, meeting or exceeding requirements for automotive, solar inverter, wind power and other advanced applications that may involve high ambient temperatures or rapid thermal cycling.
Constructed to comply with the AEC-Q200 automotive standard and featuring a flame retardant, RoHS-compliant plastic case, this Panasonic capacitor ensures both regulatory compliance and operational safety. It has a compact footprint with dimensions of 57.5mm length, 30mm width, and 51mm height, with 1.2mm diameter pins and a 4mm lead length.
Panasonic’s EZPV80356MTC is the preferred choice for reliable DC power management in advanced electronic assemblies, including frequency converters, industrial motor drives, power supplies, and renewable energy infrastructure requiring robust DC link capacitors.
Typical industrial use cases include: power factor correction networks, solar and wind power converters, electric vehicle charging systems, high-power DC bus filtering, and any application demanding stable, long-lifespan energy storage with minimal maintenance.
Discover more Panasonic film capacitors and related passive components in the Film Capacitor section on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 35F, making it suitable for significant energy storage applications.
The EZPV80356MTC is rated for a maximum DC voltage of 800V, which is ideal for DC filtering and link circuits.
It has a capacitance tolerance of ±10%, ensuring consistent performance in applications.
This capacitor features a through hole mounting design, which allows for secure PCB installation.
The lead pitch for the EZPV80356MTC is 52.5mm, facilitating stable insertion into printed circuit boards.
The dimensions are 57.5mm in length, 30mm in width, and 51mm in height.
The equivalent series resistance is 10.2mΩ, which supports high-efficiency performance with minimal losses.
It operates within a temperature range of -40°C to +105°C, suitable for various demanding applications.
Yes, it complies with the AEC-Q200 automotive standard and is RoHS compliant for safety and regulatory requirements.
The capacitor features a flame retardant plastic case and is constructed with metallized polypropylene.
It is suitable for applications such as DC filtering, renewable energy inverters, and power factor correction networks.
The Panasonic EZPV80356MTC has a total of 4 pins for electrical connections.
