Panasonic 0754 Shielded Wirewound Surface Mount Inductor with Metal Composite Core 34 μH ±20 % 3.3 A Idc ETQP5M

Panasonic ETQP5M is a 0754 shielded wirewound surface mount inductor featuring a metal composite core, providing an inductance of 34 μH with ±20% tolerance and a maximum DC current rating of 3.3 A. This model is designed to operate efficiently in harsh conditions ranging from -40°C to 150°C and complies with the automotive AEC-Q200 standard, making it highly reliable for automotive and industrial applications.

The wirewound construction combined with the metal composite core minimizes buzz noise and offers stable inductance performance even under high bias currents. The inductor’s molded package and shielding provide enhanced vibration resistance and electromagnetic interference protection, ensuring robust performance in demanding environments.

Package dimensions measure 7.5 mm in length, 7 mm in depth, and 5.4 mm in height, making it compact and suitable for modern surface mount assembly. The 0754 case style is designed for rapid pick-and-place mounting with reel packaging for manufacturing efficiency.

Core material: Metal composite ensures low eddy-current losses and noise. Inductance tolerance ±20% allows for stable circuit operation. Maximum self-resonant frequency of 100 kHz supports high-frequency applications. Low DC resistance of 132 mΩ maximizes efficiency and reduces power loss.

Compliance with RoHS directives ensures environmental safety. Mounting style: Surface mount termination for reliable PCB assembly. This series supports automotive-quality applications requiring robustness and reliability.

Typical use includes DC-DC converters, power supplies, and noise filters for drive circuitry requiring high peak current and operating temperature capabilities. These features make the Panasonic ETQP5M 0754 series an optimal choice for industrial, automotive, and electronic manufacturing sectors.
