Murata Power Solutions 6000B 2720 Unshielded Wirewound Surface Mount Inductor 68μH ±15% 9A IDC 60B683C
Specifications
| Country of Origin | India |
|---|---|
| Brand | Murata Power Solutions |
| Height | 20mm |
| Length | 27mm |
| Model | 60B683C |
| Depth | 19.5mm |
| Packaging | Reel |
| Series | 6000B |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Inductance | 68μH |
| Standards/Approvals | RoHS |
| Package/Case | 2720 |
| Maximum DC Current | 9A |
| Maximum DC Resistance | 17mΩ |
| Inductance Tolerance | ±15 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 6.07MHz |
| Inductor Construction | Wirewound |
Key Features
- Inductance value of 68 microhenries with ±15% tolerance.
- Maximum DC current rating of 9 amperes suitable for high current circuits.
- Unshielded wirewound construction designed for surface mounting.
- Compact 2720 package case with reel packaging for efficient assembly.
- Wide operating temperature range from -40°C to 85°C ensuring reliability.
- Low maximum DC resistance of 17 milliohms minimizes power loss.
- Maximum self-resonant frequency of 6.07 MHz for stable performance.
- RoHS compliant and environmentally friendly.
Product Description
Murata Power Solutions 60B683C is a 6000B series unshielded wirewound surface mount inductor with an inductance of 68μH and tolerance of ±15%. Rated for a maximum DC current of 9 A, it is engineered for performance in demanding electronic applications such as DC-DC converters, energy storage, and input/output filtering.
This inductor features a compact 2720 package with reel packaging for volume manufacturing. Its wirewound construction provides high energy storage and very low resistance (17mΩ max), promoting efficiency and heat management in circuits.
Operating temperature ranges from -40°C to 85°C, allowing usage in industrial and commercial environments with temperature variation. The termination style is surface mount, optimized for PCB solder assembly processes. The maximum self-resonant frequency is 6.07 MHz, ensuring signal integrity in switching power applications.
The product complies with RoHS standards, reflecting an environmentally conscious design. Its physical dimensions are length 27mm, height 20mm, and depth 19.5mm, making it suitable for compact electronic board layouts.
Typical industrial applications include automotive electronics, power management modules, communication equipment, and general electronic systems requiring robust filtering and energy storage solutions.
Inductance of 68 microhenries with a ±15% tolerance for precise performance. Up to 9 A maximum DC current handling capability for high power circuits. Unshielded wirewound construction providing excellent energy storage properties.
Surface mount termination style for automatic PCB assembly. Compact 2720 package and reel packaging facilitating mass production. Robust operating temperature range from -40°C to 85°C for various environments. Low resistance minimizes losses and thermal buildup.
RoHS compliant to meet environmental regulations. Stable operation up to 6.07 MHz self-resonant frequency. Physical dimensions suited for space-constrained applications. Explore the extensive range of electronic components at EnvMart, including Surface Mount Inductors designed for advanced power electronics and industrial use.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 68 microhenries (μH) with a tolerance of ±15%.
It has a maximum DC current rating of 9 amperes, making it suitable for high current circuits.
The maximum self-resonant frequency is 6.07 MHz, ensuring stable performance in switching applications.
The dimensions are 27mm in length, 20mm in height, and 19.5mm in depth, making it compact for electronic board layouts.
It features an unshielded wirewound construction, which provides excellent energy storage properties.
The operating temperature range is from -40°C to 85°C, allowing for use in various environments.
The maximum DC resistance is 17 milliohms, which helps minimize power loss in circuits.
This model has a surface mount termination style, optimized for PCB solder assembly processes.
It is packaged on a reel, facilitating efficient assembly in volume manufacturing.
Yes, this inductor is RoHS compliant, reflecting its environmentally friendly design.
Typical applications include automotive electronics, power management modules, communication equipment, and general electronic systems requiring robust filtering and energy storage solutions.
