TDK Shielded Wirewound Surface Mount Inductor with Ferrite Core, 220 μH ±20/±30 %, 450 mA IDC, Package 5045 VLS5045EX-221M
Specifications
| Country of Origin | China |
|---|---|
| Brand | TDK |
| Height | 4.5mm |
| Length | 5mm |
| Model | VLS5045EX-221M |
| Depth | 5mm |
| Series | VLS-EX |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 220μH |
| Standards/Approvals | Halogen Free, Lead Free, REACH, RoHS, SVHC-free |
| Package/Case | 5045 |
| Maximum DC Current | 450mA |
| Maximum DC Resistance | 1.365Ω |
| Inductance Tolerance | ±20/±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Magnetic shield type wound inductor optimized for power circuits.
- Ferrite core construction ensures high magnetic shield performance.
- Suitable for high-density mounting with a compact 5045 package size.
- Maximum DC resistance up to 1.365 Ω for effective circuit performance.
- Wide operating temperature range from -40°C to 105°C.
- Halogen free, lead free, REACH, RoHS and SVHC compliant.
- Designed for use in TVs, set-top boxes, gaming, and other AV equipment.
Product Description
The TDK VLS5045EX-221M is a shielded wirewound surface mount inductor featuring a ferrite core designed for power circuit applications. This inductor provides an inductance of 220 μH with a tolerance of ±20/±30 % that guarantees performance reliability for demanding electrical environments.
Constructed with a high magnetic shield achieved through ferrite magnetic material, it supports high-density mounting configurations, making it ideal for compact electronic assemblies. The VLS5045EX-221M includes a maximum DC current rating of 450 mA and maximum DC resistance of 1.365 Ω, ensuring efficient power handling and minimal losses.
This surface mount inductor comes in a 5045 package case with compact dimensions of 5 mm length, 5 mm depth, and 4.5 mm height. It is suitable for applications operating within a temperature range of -40°C to 105°C, complying with automotive standards.
Manufactured under strict environmental standards, this product is halogen free, lead free, REACH, RoHS, and SVHC-free, supporting safe and eco-friendly electronic design. Magnetic shield type wound inductor for power circuits.
Ferrite core material ensures effective magnetic shielding. Compact 5045 package suits high-density PCB mounting. Rated for 450 mA maximum DC current with low DC resistance. Wide operational temperature range: -40°C to 105°C.
Halogen free and compliant with major environmental regulations. Applications include TVs, set-top boxes, gaming hardware, and AV equipment. Surface mount termination style facilitates automated assembly.
This component is highly reliable and suitable for industrial, commercial electronics manufacturing environments. It enhances power efficiency and ensures device longevity when integrated into various electronic circuits.
Explore more electronic components and Surface Mount Inductors by TDK on EnvMart for industrial, laboratory, manufacturing, and consumer electronics applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 220 μH with a tolerance of ±20/±30 %.
It has a maximum DC current rating of 450 mA, ensuring efficient power handling.
The dimensions of the 5045 package are 5 mm in length, 5 mm in depth, and 4.5 mm in height.
The maximum DC resistance is 1.365 Ω, which aids in effective circuit performance.
This inductor operates within a temperature range of -40°C to 105°C.
It features a ferrite core construction, which ensures high magnetic shield performance.
It is halogen free, lead free, and compliant with REACH, RoHS, and SVHC standards.
The termination style for this model is surface mount, facilitating automated assembly.
This inductor is suitable for applications in TVs, set-top boxes, gaming hardware, and other AV equipment.
It is a wirewound inductor, optimized for power circuit applications.
The series designation for this model is VLS-EX.
This inductor is manufactured in China.
