TDK SLF 12575 Shielded Wirewound Surface Mount Inductor with Ferrite Core 100 μH ±20/±30% 1.9 A Idc SLF12575T-101M1R9-PF
Specifications
| Country of Origin | China |
|---|---|
| Brand | TDK |
| Height | 7.5mm |
| Operating Temperature Range | - 40 to +105°C (including self-temperature rise) |
| Length | 12.5mm |
| Model | SLF12575T-101M1R9-PF |
| Depth | 12.5mm |
| Packaging | 500 pieces per reel |
| Series | SLF |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 100μH |
| Standards/Approvals | Halogen Free, Lead Free, REACH SVHC-Free, RoHS |
| Package/Case | 12575 |
| Maximum DC Current | 1.9A |
| Maximum DC Resistance | 150mΩ |
| Inductance Tolerance | ±20/±30 % |
| Termination Style | Surface Mount |
| Inductor Construction | Wirewound |
Key Features
- Constructed with a ferrite core for efficient magnetic shielding.
- Wirewound design ensures stable inductance and durability.
- Compact surface mount package case 12575 sized 12.5 mm by 7.5 mm by 12.5 mm.
- Operating temperature range from -40°C to 105°C, suitable for varied environments.
- Maximum DC resistance rated at 150 mΩ for low power loss.
- Packaged with 500 pieces per reel for bulk assembly needs.
- Compliant with RoHS, REACH, lead free, and halogen free standards.
- Designed specifically for power circuit applications in electronics.
Product Description
The TDK SLF12575T-101M1R9-PF is a high-quality shielded wirewound surface mount inductor designed for power circuit applications. Featuring a ferrite core, it offers an inductance of 100 μH ±20/±30% tolerance and supports a maximum DC current of 1.9 A. Its compact 12575 package case measures 12.5 mm length, 7.5 mm height, and 12.5 mm depth, making it ideal for assembly where space-saving surface mount technology is required.
This component operates reliably within a temperature range of -40°C to 105°C, accommodating environmental variations including self-temperature rise during operation. The inductor construction ensures effective magnetic shielding due to its wirewound design combined with a ferrite core, which minimizes interference in power circuits.
With a maximum DC resistance of 150 milliohms, the device maintains efficiency and reduces power losses. It is compliant with important environmental and safety standards including RoHS, REACH SVHC-Free, Halogen Free, and Lead Free, supporting sustainable and safe electronic manufacturing.
Typically used in thin-screen televisions, LCDs, audio-visual equipment, and gaming devices, this inductor is reliable for various electronic applications requiring stable inductance and durability.
Constructed with ferrite core and magnetic shielding for power circuits. Wirewound surface mount design enables low profile and efficient performance. Compact dimensions of 12.5 mm length, 7.5 mm height, and 12.5 mm depth.
Wide operating temperature from -40°C to 105°C fits diverse industrial conditions. Low maximum DC resistance of 150 mΩ ensures minimal power loss. Compliant with multiple environmental standards ensuring regulatory adherence.
Ideal for use in consumer electronics like TVs, LCDs, and gaming equipment. Available in reels of 500 pieces for efficient manufacturing workflow.
This surface mount inductor by TDK exemplifies a robust solution for enhancing power circuit performance in industrial, consumer electronics, and manufacturing sectors. For reliable components that meet environmental standards, explore our comprehensive Electronics & Electricals and Surface Mount Inductors categories at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 100 μH with a tolerance of ±20/±30%.
It supports a maximum DC current of 1.9 A.
The dimensions are 12.5 mm in length, 7.5 mm in height, and 12.5 mm in depth.
The operating temperature range is from -40°C to +105°C, including self-temperature rise during operation.
The inductor is constructed with a ferrite core for efficient magnetic shielding.
It is packaged with 500 pieces per reel for bulk assembly needs.
It complies with RoHS, REACH SVHC-Free, Halogen Free, and Lead Free standards.
The maximum DC resistance is rated at 150 mΩ, which helps in minimizing power loss.
The termination style is surface mount, suitable for space-saving applications.
It is typically used in power circuit applications in consumer electronics like thin-screen televisions, LCDs, and gaming devices.
The inductor features a wirewound construction, ensuring stable inductance and durability.
This inductor belongs to the SLF series of TDK products.
