Murata Power Solutions Through Hole Pulse Transformer 1CT:1CT Turns Ratio, 1000 μH Primary Inductance, 0.45Ω 78615/8C

Murata Power Solutions 78615/8C Through Hole Pulse Transformer from the 786 series is engineered for use in coupling circuits, thyristor and triac firing circuits, and compact switch mode power supplies. It features a primary inductance of 1000 μH and primary DC resistance of 0.45Ω, providing efficient energy transfer with minimal losses.

This pulse transformer is designed with a 1CT:1CT turns ratio, modifiable as per application requirements by series connection of windings. The through hole mounting and pin termination ensure secure and reliable PCB integration, suitable for industrial electronic assemblies.

With a leakage inductance of 11.9 μH and an isolation voltage of 1kV, the transformer maintains signal integrity while ensuring electrical isolation critical for safety and system stability. The device operates reliably within an ambient temperature range of 0°C to 70°C, suitable for varied industrial environments.

Compact form factor dimensions of 9.52 mm length, 9.79 mm depth, and 9 mm width facilitate space-efficient designs. The transformer weighs approximately 1.1 grams and complies with RoHS standards, reflecting environmental responsibility in manufacturing.

Manufactured in China, this transformer supports high-quality specifications suitable for electronics, power supplies, and industrial applications including automation, control systems, and small power supplies. Its versatile use cases include electrical isolation, signal coupling, and filtering in commercial and industrial electronic circuits.

Set contains 1 Pulse Transformer 786 Series 78615/8C. This pulse transformer is designed for coupling, thyristor/triac firing, and compact switch mode power supply functions. Standard 1CT:1CT turns ratio with modification options by series connected windings.

Through hole mount with six pins for robust PCB installation. Nominal primary inductance of 1000 μH and primary DC resistance of 0.45Ω reduces electrical losses. Leakage inductance of 11.9 μH preserves signal fidelity. Isolation voltage rating of 1kV ensures electrical safety and isolation.

Operates within temperature range from 0°C to 70°C for dependable performance. Compact dimensions optimize PCB space and design constraints. RoHS compliant and manufactured in China. Explore a wide range of Pulse Transformers and power supplies at EnvMart for industrial, laboratory, HVAC, manufacturing, and commercial electronic applications.
