Murata Power Solutions Through Hole Pulse Transformer 3:71 Turns Ratio, 4000 μH Primary Inductance, 0.92Ω Primary 78602/16C
Specifications
| Country of Origin | China |
|---|---|
| Brand | Murata Power Solutions |
| Length | 9.52mm |
| Model | 78602/16C |
| Depth | 6.35mm |
| Gross Weight | 1.1g |
| Width | 9mm |
| Mount Type | Through Hole |
| Series | 786 |
| Termination Type | Pin |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | 0°C |
| Standards/Approvals | RoHS |
| Number of Pins | 6 |
| Isolation Voltage | 1kV |
| Primary Inductance | 4000μH |
| Turns Ratio | 3:71 |
| Primary DC Resistance | 0.92Ω |
| Leakage Inductance | 0.71μH |
| Turns Ratio3 | 71 |
Key Features
- Compact through-hole mounting design ensures easy PCB integration.
- Primary inductance of 4000 microhenries offers reliable energy transfer.
- Low primary DC resistance of 0.92 ohms for enhanced efficiency.
- Supports 1 kV isolation voltage for safe operation in electronic circuits.
- Wide operating temperature range from 0°C to 70°C ensures durability.
- Leakage inductance of 0.71 μH minimizes signal loss and interference.
- Standard 6-pin termination type improves connection stability.
- Lightweight at 1.1 grams, suitable for various electronic devices.
Product Description
Murata Power Solutions 78602/16C is a Through Hole Pulse Transformer designed for precise signal coupling, thyristor and triac firing, and compact switch mode power supply applications. Its 3:71 turns ratio, combined with a primary inductance of 4000 μH and a low primary DC resistance of 0.92Ω, enables efficient energy transfer with minimal power loss.
This pulse transformer features a through-hole mount type with 6 pins for robust circuit connections. The device offers a compact footprint, measuring 9.52 mm in length, 9 mm in width, and 6.35 mm in depth, while weighing just 1.1 grams, making it suitable for high-density PCB layouts.
Designed to operate reliably in temperature conditions ranging from 0°C to 70°C, it withstands typical electronic device environments. The 0.71 μH leakage inductance contributes to excellent signal integrity by reducing interference and noise.
The unit also supports an isolation voltage of 1 kV, providing robust insulation and enhancing safety in power supply and signal isolation applications. Its pin termination type facilitates secure and consistent soldering connections.
Murata Power Solutions 78602/16C pulse transformer meets RoHS compliance standards, ensuring it adheres to essential environmental and safety regulations. Commonly used in industrial, laboratory, construction, and HVAC sectors, this pulse transformer delivers reliable performance in demanding power supply and control circuits.
Explore the range of Pulse Transformers and related power supply components at EnvMart for your electronic design and manufacturing needs. Compact through-hole mounting design ensures easy PCB integration. Primary inductance of 4000 microhenries offers reliable energy transfer.
Low primary DC resistance of 0.92 ohms for enhanced efficiency. Supports 1 kV isolation voltage for safe operation in electronic circuits. Wide operating temperature range from 0°C to 70°C ensures durability. Leakage inductance of 0.71 μH minimizes signal loss and interference.
Standard 6-pin termination type improves connection stability. Dimensions of 9.52 mm length, 9 mm width, and 6.35 mm depth for compact applications. Lightweight at 1.1 grams, suitable for various electronic devices. Compliance with RoHS standards guarantees environmental safety.
