Renesas Electronics Brushed DC Motor Driver IC 46V 4A 15-Pin Multiwatt L298N
Specifications
| Country of Origin | Morocco |
|---|---|
| Brand | Renesas Electronics |
| Height | 10.7mm |
| Length | 19.6mm |
| Model | L298N |
| Width | 5mm |
| Motor Type | Brushed DC Motor |
| Mount Type | Through Hole |
| Series | L298 |
| Configuration | Dual Full-Bridge Driver |
| Output Current | 2A |
| Maximum Operating Temperature | 130°C |
| Package Type | Multiwatt |
| Minimum Operating Temperature | -25°C |
| Pin Count | 15 |
| Maximum Collector Emitter Voltage Vceo | 46V |
| Maximum Supply Voltage | 46V |
| Minimum Supply Voltage | 4.8V |
| Supply Current | 70mA |
| Maximum IGBT Collector Current | 4A |
| Typical Switching Frequency | 40kHz |
| Inverter Power Rating | 25W |
| DC stepper motor controllerL293E 4.5-36VBrand | STMicroelectronics |
| STMicroelectronics L292 Motor Driver IC 15-Pin, MULTIWATT VBrand | STMicroelectronics |
Key Features
- Supports brushed DC motors with high current capacity.
- Dual full-bridge driver circuit for relays, solenoids, DC, and stepper motors.
- Operates with supply voltage up to 46 V and output current up to 2 A per channel.
- Through-hole mounting in a rugged 15-pin Multiwatt package.
- Integrated over-temperature and high noise immunity for reliable performance.
- Suitable for use in relays, solenoids, and motor control circuits.
Product Description
The Renesas Electronics L298N is a robust brushed DC motor driver IC, featuring a 15-pin Multiwatt package engineered for use in demanding industrial and automation applications. With support for voltages up to 46 V and delivering up to 4 A of total DC current, this dual full-bridge driver efficiently powers DC motors, relays, solenoids, and stepper motors.
The device is designed with two enable inputs that can independently control the driver channels, making it ideal for applications requiring simultaneous or separate motor operation. Its through-hole mounting format allows for easy integration and reliable mechanical stability on printed circuit boards.
Advanced protection circuitry is integral to the L298N, including over-temperature shutdown and high noise immunity, ensuring long-term operation in harsh conditions. The output current capability reaches up to 2 A per channel, with logical "0" input voltages up to 1.5 V for superior control signal resilience.
Typical use cases for the L298N include automation equipment, laboratory motorized instruments, robotics, manufacturing machinery, and electronic motor control. The supply input enables separate logic supply and drive voltages, increasing design flexibility. The IC accepts standard TTL logic levels, making it compatible with a wide range of controllers and microprocessors.
Physically, the component measures 19.6 mm in length, 5 mm in width, and 10.7 mm in height, fitting compact control boards. The wide operating temperature range from -25°C to +130°C supports both indoor and industrial field applications.
The L298N stands out for low saturation voltage and dual-bridge architecture, ensuring power-efficient and reliable driving of inductive loads. Its flexible configuration makes it suitable for systems that drive relays, solenoids, and various motors requiring up to 46 V and 2 A of current per driver channel.
For further industrial part selection, explore more Motor Driver ICs, Power Management components, and Renesas Electronics solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The L298N can deliver up to 2 A of output current per channel, with a total maximum collector-emitter current of 4 A.
This motor driver IC operates with a maximum supply voltage of 46 V.
The L298N measures 19.6 mm in length, 5 mm in width, and 10.7 mm in height.
It supports brushed DC motors, as well as relays, solenoids, and stepper motors.
This model features through-hole mounting, allowing for easy integration into printed circuit boards.
The device operates within a temperature range of -25°C to +130°C.
The L298N has a total of 15 pins.
The typical switching frequency for this motor driver IC is 40 kHz.
Yes, it includes integrated over-temperature shutdown and high noise immunity for reliable performance.
The minimum supply voltage required for the L298N is 4.8 V.
The L298N is configured as a dual full-bridge driver, allowing control of two motors or channels independently.
The L298N is manufactured in Morocco.
