onsemi DC Motor Motor Driver IC Half Bridge, 28-Pin SOIC Package NCV7708FDWR2G

onsemi NCV7708FDWR2G is a DC Motor Motor Driver IC specifically engineered as a fully protected hex half bridge driver optimized for automotive and industrial motion control applications.

This device features six independent high-side and low-side drivers that are configurable independently, enabling complex motor control such as forward, reverse, brake, and high impedance modes through H-Bridge operation.

The integrated protections include freewheeling protection with internal upper and lower clamp diodes to protect against inductive loads, as well as over- and undervoltage lockout, fault reporting, current limiting, and overtemperature protection to ensure durability and reliability in demanding environments.

Control is facilitated via a standard SPI interface capable of 5 MHz switching frequency, thus enabling precise and efficient operation. The IC supports compatibility with both 3.3 V and 5 V logic systems, making it versatile for various electronic control architectures.

This motor driver IC comes in a compact SOIC-28 surface mount package with physical dimensions of 18.05 mm length, 7.6 mm width, and 2.36 mm height, combining high power density and enhanced thermal performance due to fused internal leads.

Designed to meet automotive standard AEC-Q100, the NCV7708FDWR2G is well-suited for industrial motor management systems, HVAC equipment, and other motor-driven applications requiring robust, high-reliability components capable of operating between -40°C and 150°C.

Provides a fully protected hex half bridge driver for DC motor control. Six independently configurable drivers for versatile motor driving modes. Integrated freewheeling protection with internal clamp diodes for enhanced durability.

Supports SPI interface with a typical switching frequency of 5 MHz. Wide operating voltage range from 3.15 V to 5.25 V. Operating temperature range from -40°C to 150°C suitable for harsh environments. Low supply current of 3 mA for energy-efficient operation.

Compact 28-pin SOIC package with dimensions length 18.05 mm, width 7.6 mm, height 2.36 mm. Complies with automotive standard AEC-Q100 ensuring high reliability.

The NCV7708FDWR2G motor driver IC is ideal for automotive and industrial uses, including DC motor management, HVAC systems, and precise motion control solutions. Explore more products in the Motor Driver IC category at EnvMart for a wide selection of high-quality components.
