ROHM Brushed DC Motor Driver IC, Half Bridge, 2A, 7-Pin, HRP7 Package BD6232HFP-TR

Free Delivery in India | Lowest Global Shipping Charges

ROHM Brushed DC Motor Driver IC, Half Bridge, 2A, 7-Pin, HRP7 Package BD6232HFP-TR

Name: ROHM Brushed DC Motor Driver IC, Half Bridge, 2A, 7-Pin, HRP7 Package BD6232HFP-TR
Brand: ROHM
SKU: 88754
Price: 5.47 USD
Availability: InStock



Category Motor Driver IC Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	1.9mm
Length	9.39mm
Model	BD6232HFP-TR
Width	8mm
Motor Type	Brushed DC Motor
Mount Type	Surface
Series	BD6232HFP
Configuration	Half Bridge
Output Current	2A
Maximum Operating Temperature	85°C
Package Type	HRP7
Minimum Operating Temperature	-40°C
Pin Count	7
Maximum Supply Voltage	32V
Minimum Supply Voltage	6V
Supply Current	3.5mA
Maximum IGBT Collector Current	2A
Typical Switching Frequency	100kHz
Inverter Power Rating	1.6W

Key Features

Supports brushed DC motor control with Half Bridge output topology.
Delivers a maximum output current of 2A, ensuring robust drive performance for low- to medium-power DC motors.
Wide supply voltage range from 6V to 32V for flexible motor drive applications.
Operates reliably in temperatures ranging from -40°C to 85°C, suitable for industrial and commercial environments.
Compact HRP7 package with seven pins for easy integration into surface-mount PCB designs.
Typical switching frequency of 100kHz optimizes motor response and efficiency.
Low supply current of 3.5mA reduces overall system power consumption.
Ideal for applications such as industrial automation, robotics, handheld electronics, and instrumentation requiring precise DC motor control.

Product Description

The ROHM BD6232HFP-TR is a highly integrated brushed DC motor driver IC designed for efficient, reliable performance in industrial, automation, and embedded applications. Housed in a compact 7-pin HRP7 surface mount package, this IC is tailored for designs that require robust DC motor actuation in limited board space.

Equipped with a Half Bridge output topology, this driver IC supports direct drive of brushed DC motors with a maximum output current rating of 2A. Its supply voltage range spans from 6V to 32V, accommodating both portable and fixed installation systems and supporting a variety of DC motors. The IC is engineered to sustain reliable operation across a wide ambient temperature range from -40°C up to 85°C, ensuring consistent performance in demanding industrial and commercial settings.

The BD6232HFP-TR operates with a typical switching frequency of 100kHz, optimizing the dynamic response of motor systems while controlling electromagnetic interference. With an inverter power rating of 1.6W and a low supply current requirement of just 3.5mA, the IC helps keep overall power consumption and heating to a minimum. The seven-pin HRP7 package allows for straightforward surface-mount assembly onto standard printed circuit boards, making it an optimal choice for mass production and compact layouts.

Additional features include a 2A maximum IGBT collector current, robust half bridge configuration, and standardized dimensions (9.39mm length, 8mm width, and 1.9mm height). Safety and reliability are further assured by contoured support for industrial operating ranges and compliance with relevant regulatory standards, with no automotive-specific certification claimed for this variant.

The BD6232HFP-TR is well suited for use in precision motor control circuits within applications such as industrial automation systems, robotic actuators, test instrumentation, surveillance devices, and a range of battery-powered electronics. Its performance and efficient operation allow designers to implement reliably controlled movements and positioning with minimal external components.

When designing, always refer to the latest ROHM product datasheet for comprehensive application guidelines, pinout details, and reference circuit implementations. Explore more industrial-grade motor driver components from ROHM under the Motor Driver IC category on EnvMart for integrated solutions to your motion control needs.
