ROHM Brushed DC Motor Driver IC 8-Pin Surface Mount HRP Package 3-5.5V 2A Output BD6212HFP-TR

Free Delivery in India | Lowest Global Shipping Charges

ROHM Brushed DC Motor Driver IC 8-Pin Surface Mount HRP Package 3-5.5V 2A Output BD6212HFP-TR

Name: ROHM Brushed DC Motor Driver IC 8-Pin Surface Mount HRP Package 3-5.5V 2A Output BD6212HFP-TR
Brand: ROHM
SKU: 200418
Price: 3.46 USD
Availability: InStock



Category Motor Driver IC Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	1.9mm
Length	9.39mm
Model	BD6212HFP-TR
Width	8mm
Motor Type	Brushed DC Motor
Mount Type	Surface
Series	BD621
Configuration	H Bridge
Output Current	2A
Maximum Operating Temperature	85°C
Package Type	HRP
Minimum Operating Temperature	-40°C
Pin Count	8
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	3V
Supply Current	2μA
Typical Switching Frequency	100kHz
Inverter Power Rating	1.6W

Key Features

Supports brushed DC motors with an H-Bridge configuration for bidirectional control.
Operates with supply voltage from 3V to 5.5V ensuring versatile power compatibility.
Delivers output current up to 2 amperes for robust motor driving capability.
Features low supply current consumption of 2 microamperes for energy-efficient operation.
Typical switching frequency is 100 kHz enabling precise motor speed control.
Designed to operate between -40°C to 85°C for reliable performance in harsh environments.
Compact dimensions with a height of 1.9mm, length of 9.39mm, and width of 8mm minimize PCB space usage.
Surface mount HRP package provides easy integration on printed circuit boards.

Product Description

ROHM BD6212HFP-TR is a Brushed DC Motor Driver IC designed for efficient control of brushed DC motors. This 8-pin device features an H-Bridge configuration to enable bidirectional motor control. It supports a supply voltage range from 3V to 5.5V and can deliver an output current of up to 2A, making it suitable for moderate power motor applications.

The IC operates with a typical switching frequency of 100 kHz, which aids in precise and smooth motor speed regulation. Its very low supply current of 2μA helps conserve energy during operation.

The device is housed in a compact HRP surface mount package with dimensions of 1.9mm in height, 9.39mm in length, and 8mm in width, optimized for PCB space efficiency. The operating temperature range from -40°C to 85°C ensures functionality across a broad range of industrial and consumer environments.

While there are no specific automotive standards or approvals for this component, it serves well in various industrial, electronics, and power management applications where reliable brushed DC motor control is needed.

Supports brushed DC motors with H-Bridge architecture. Supply voltage range: 3 to 5.5 volts. Output current capacity: 2 amperes. Low supply current consumption minimizes power use. Compact 8-pin HRP surface mount packaging.

Operating temperature from -40°C to +85°C. Switching frequency optimized at 100 kHz. This IC is ideal for motor drive circuits in industrial automation, robotics, HVAC systems, and other electronics requiring efficient motor control.
